Kubernetes WordPress Helm Chart

In this tutorial, we’ll use the Helm API of @pulumi/kubernetes to deploy v9.6.0 of the Wordpress Helm Chart to a Kubernetes cluster. Pulumi will expand the Helm Chart and submit the expanded YAML to the cluster.


Running the App

Start by downloading the example code.

If you haven’t already, follow the steps in Pulumi Installation and Setup and Configuring Pulumi Kubernetes to get set up with Pulumi and Kubernetes.

Now, install dependencies:

$ npm install

Create a new stack:

$ pulumi stack init
Enter a stack name: wordpress-dev

Preview the deployment of the application.

Preview the deployment of the application and then perform the deployment:

pulumi up
Previewing update (wordpress-dev)

View Live: https://app.pulumi.com/example/wordpress/wordpress-dev/previews/cc683bd2-1e19-49c9-8a88-792c44e3b020

     Type                                         Name                         Plan
 +   pulumi:pulumi:Stack                          wordpress-dev-wordpress      create
 +   └─ kubernetes:helm.sh:Chart                  wpdev                        create
 +      ├─ kubernetes:core:Secret                 default/wpdev-mariadb        create
 +      ├─ kubernetes:core:Secret                 wpdev-wordpress              create
 +      ├─ kubernetes:core:Service                default/wpdev-mariadb        create
 +      ├─ kubernetes:core:Service                wpdev-wordpress              create
 +      ├─ kubernetes:core:ConfigMap              default/wpdev-mariadb        create
 +      ├─ kubernetes:core:PersistentVolumeClaim  wpdev-wordpress              create
 +      ├─ kubernetes:apps:StatefulSet            default/wpdev-mariadb        create
 +      └─ kubernetes:apps:Deployment             wpdev-wordpress              create

    + 10 to create

Do you want to perform this update? yes
Updating (ts-helm-wordpress)

View Live: https://app.pulumi.com/example/wordpress/ts-helm-wordpress/updates/7

     Type                                         Name                         Status
 +   pulumi:pulumi:Stack                          wordpress-dev-wordpress      create
 +   └─ kubernetes:helm.sh:Chart                  wpdev                        created
 +      ├─ kubernetes:core:Secret                 default/wpdev-mariadb        created
 +      ├─ kubernetes:core:Secret                 wpdev-wordpress              created
 +      ├─ kubernetes:core:PersistentVolumeClaim  wpdev-wordpress              created
 +      ├─ kubernetes:core:Service                wpdev-wordpress              created
 +      ├─ kubernetes:core:ConfigMap              default/wpdev-mariadb        created
 +      ├─ kubernetes:core:Service                default/wpdev-mariadb        created
 +      ├─ kubernetes:apps:StatefulSet            default/wpdev-mariadb        created
 +      └─ kubernetes:apps:Deployment             wpdev-wordpress              created

    frontendIp: ""

    + 10 created

Duration: 53s

We can see here in the ---outputs:--- section that Wordpress was allocated a public IP, in this case It is exported with a stack output variable, frontendIp. We can use curl and grep to retrieve the <title> of the site the proxy points at.

$ curl -sL $(pulumi stack output frontendIp):80 | grep "<title>"
<title>User&#039;s Blog! &#8211; Just another WordPress site</title>

You can also navigate to the site in a web browser.

When you’re done, you can remove these resources with pulumi destroy:

pulumi destroy --skip-preview
Destroying (wordpress-dev)

View Live: https://app.pulumi.com/example/wordpress/wordpress-dev/updates/8

     Type                                         Name                         Status
 -   pulumi:pulumi:Stack                          wordpress-dev-wordpress      deleted
 -   └─ kubernetes:helm.sh:Chart                  wpdev                        deleted
 -      ├─ kubernetes:core:Secret                 wpdev-wordpress              deleted
 -      ├─ kubernetes:core:Secret                 default/wpdev-mariadb        deleted
 -      ├─ kubernetes:core:ConfigMap              default/wpdev-mariadb        deleted
 -      ├─ kubernetes:core:Service                default/wpdev-mariadb        deleted
 -      ├─ kubernetes:core:PersistentVolumeClaim  wpdev-wordpress              deleted
 -      ├─ kubernetes:core:Service                wpdev-wordpress              deleted
 -      ├─ kubernetes:apps:StatefulSet            default/wpdev-mariadb        deleted
 -      └─ kubernetes:apps:Deployment             wpdev-wordpress              deleted

  - frontendIp: ""

    - 10 deleted

Duration: 7s
