Stacks

    Every Pulumi program is deployed to a stack. A stack is an isolated, independently configurable instance of a Pulumi program. Stacks are commonly used to denote different phases of development (such as development, staging, and production) or feature branches (such as feature-x-dev).

    A project can have as many stacks as you need. By default, Pulumi creates a stack for you when you start a new project using the pulumi new command.

    Create a stack

    To create a new stack, use pulumi stack init stackName. This creates an empty stack stackName and sets it as the active stack. The project that the stack is associated with is determined by finding the nearest Pulumi.yaml file.

    The stack name must be unique within a project. Stack names may only contain alphanumeric characters, hyphens, underscores, or periods.

    $ pulumi stack init staging


    The stack name is specified in one of the following formats:

    1. stackName: Identifies the stack stackName in the current user account or default organization, and the project specified by the nearest Pulumi.yaml project file.
    2. orgName/stackName: Identifies the stack stackName in the organization orgName, and the project specified by the nearest Pulumi.yaml project file.
    3. orgName/projectName/stackName: Identifies the stack stackName in the organization orgName and the project projectName. projectName must match the project specified by the nearest Pulumi.yaml project file.

    For self-managed backends, the orgName portion of the stack name must always be the constant value organization.

    Additionally, backends initialized with a Pulumi CLI older than v3.61.0 support only the first format (stackName). You can upgrade these to support the other formats with the pulumi state upgrade command. See State > Scoping for more details.

    Given the stack my-org/my-project/dev, the following are all equivalent if the current organization is my-org and the current project is my-project:

    my-org/my-project/dev
    my-org/dev
    dev


    In some contexts, stack names will be presented in their fully-qualified format (orgName/projectName/stackName) even if provided using shorthand (stackName or orgName/stackName) as input.

    While stacks with applied configuration settings will often be accompanied by Pulumi.<stack-name>.yaml files, these files are not created by pulumi stack init. They are created and managed with pulumi config. For information on how to populate your stack configuration files, see Configuration.

    Listing stacks

    To see the list of stacks associated with the current project (the nearest Pulumi.yaml file), use pulumi stack ls.

    $ pulumi stack ls
    NAME                                      LAST UPDATE              RESOURCE COUNT
    jane-dev                                  4 hours ago              97
    staging*                                  n/a                      n/a
    broomellc/test                            2 weeks ago              121


    Stack names in the listing will be partially qualified if they are associated with an organization or project different from the default for the context.

    Select a stack

    The top-level pulumi operations config, preview, update and destroy operate on the active stack. To change the active stack, run pulumi stack select.

    $ pulumi stack select jane-dev

    $ pulumi stack ls
    NAME                                      LAST UPDATE              RESOURCE COUNT
    jane-dev*                                 4 hours ago              97
    staging                                   n/a                      n/a
    broomellc/test                            2 weeks ago              121


    To select a stack that is part of an organization, use the fully-qualified stack name, either orgName/stackName or orgName/projectName/stackName:

    $ pulumi stack select mycompany/prod

    $ pulumi stack ls
    NAME                                      LAST UPDATE              RESOURCE COUNT
    mycompany/prod*                            4 hours ago              97
    mycompany/staging                          4 hours ago              97
    dev                                       n/a                      n/a


    Generate an update plan

    Update plans are currently in experimental preview and will only show up in --help if the environment variable PULUMI_EXPERIMENTAL is set to true.

    To preview an update of the currently selected stack and save that plan run pulumi preview --save-plan=plan.json. The operation uses the latest configuration values for the active stack.

    Your program code can distinguish between execution for preview and update operations by using pulumi.runtime.isDryRun().

    Update a stack

    To update the currently selected stack, run pulumi up. If you saved a plan from a preview you can pass that in to constrain the update to only doing what was planned with pulumi up --plan=plan.json. The operation uses the latest configuration values for the active stack.

    View stack resources

    To view details of the currently selected stack, run pulumi stack with no arguments. This displays the metadata, resources and output properties associated with the stack.

    $ pulumi stack
    Current stack is jane-dev:
        Last updated 1 week ago (2018-03-02 10:26:09.850357 -0800 PST)
        Pulumi version v0.11.0
        Plugin nodejs [language] version 0.11.0
        Plugin aws [resource] version 0.11.0

    Current stack resources (3):
        TYPE                                             NAME
        pulumi:pulumi:Stack                              webserver-jane-dev
        aws:ec2/securityGroup:SecurityGroup              web-secgrp
        aws:ec2/instance:Instance                        web-server-www

    Current stack outputs (2):
        OUTPUT                                           VALUE
        publicDns                                        ec2-18-218-85-197.us-east-2.compute.amazonaws.com
        publicIp                                         18.218.85.197

    Use `pulumi stack select` to change stack; `pulumi stack ls` lists known ones


    Stack tags

    Stacks have associated metadata in the form of tags, with each tag consisting of a name and value. A set of built-in tags are automatically assigned and updated each time a stack is updated (such as pulumi:project, pulumi:runtime, pulumi:description, gitHub:owner, gitHub:repo, vcs:owner, vcs:repo, and vcs:kind). To view a stack’s tags, run pulumi stack tag ls.

    Stack tags are only supported with the Pulumi Cloud backend.

    Custom tags can be assigned to a stack by running pulumi stack tag set <name> <value> and can be used to customize the grouping of stacks in the Pulumi Cloud. For example, if you have many projects with separate stacks for production, staging, and testing environments, it may be useful to group stacks by environment instead of by project. To do this, you could assign a custom tag named environment to each stack. For example, running pulumi stack tag set environment production assigns a custom environment tag with a value of production to the active stack. Once you’ve assigned an environment tag to each stack, you’ll be able to group by Tag: environment in the Pulumi Cloud.

    As a best practice, custom tags should not be prefixed with pulumi:, gitHub:, or vcs: to avoid conflicting with built-in tags that are assigned and updated with fresh values each time a stack is updated.

    Tags can be deleted by running pulumi stack tag rm <name>.

    Stack outputs

    A stack can export values as stack outputs. These outputs are shown during an update, can be easily retrieved with the Pulumi CLI, and are displayed in Pulumi Cloud. They can be used for important values like resource IDs, computed IP addresses, and DNS names.

    To export values from a stack, use the following definition in the top-level of the entrypoint for your project:

    exports.url = resource.url;

    export let url = resource.url;

    pulumi.export("url", resource.url)

    ctx.Export("url", resource.Url)

    public class MyStack : Stack
    {
        public MyStack()
        {
            ...
            this.Url = resource.Url;
        }

        // 'url' is the output name. By default, it would take the property name 'Url'.
        [Output("url")] public Output<string> Url { get; set; }
    }

    public class App {
        public static void main(String[] args) {
            Pulumi.run(App::stack);
        }

        public static void stack(Context ctx) {
            ctx.export("url", resource.url());
        }
    }

    outputs:
      url: ${resource.url}


    From the CLI, you can then use pulumi stack output url to get the value and incorporate into other scripts or tools.

    The value of a stack export can be a regular value, an Output, or a Promise (effectively, the same as an Input). The actual values are resolved after pulumi up completes.

    Stack exports are effectively JSON serialized, though quotes are removed when exporting strings.

    For example, the following statements:

    exports.x = "hello"
    exports.o = {num: 42}

    export let x = "hello";
    export let o = {num: 42};

    pulumi.export("x", "hello")
    pulumi.export("o", {'num': 42})

    ctx.Export("x", pulumi.String("hello"))
    ctx.Export("o", pulumi.Map(map[string]pulumi.Input{
        "num": pulumi.Int(42),
    }))

    class MyStack : Stack
    {
        [Output] public Output<string> x { get; set; }
        [Output] public Output<ImmutableDictionary<string, int>> o { get; set; }

        public MyStack()
        {
            this.x = Output.Create("hello");
            this.o = Output.Create(
                new Dictionary<string, int> { { "num", 42 } }
                    .ToImmutableDictionary());
        }
    }

    public static void stack(Context ctx) {
        ctx.export("x", Output.of("hello"));
        ctx.export("o", Output.of(Map.of(
                "num", "42"
        )));
    }

    outputs:
      x: hello
      o:
        num: 42


    produce the following stack outputs:

    $ pulumi stack output x
    hello
    $ pulumi stack output o
    {"num": 42}


    The full set of outputs can be rendered as JSON by using pulumi stack output --json:

    $ pulumi stack output --json
    {
      "x": "hello",
      "o": {
          "num": 42
      }
    }

    Note: If you export an actual resource, it too will be JSON serialized. This usually isn’t what you want, especially because some resources are quite large. For example, if you only want to export the resource’s ID or name, just export those properties directly.

    Stack outputs respect secret annotations and are encrypted appropriately. If a stack contains any secret values, their plaintext values will not be shown by default. Instead, they will be displayed as secret in the CLI. Pass --show-secrets to pulumi stack output to see the plaintext value.

    Getting the current stack programmatically

    The getStack getStack get_stack context.Stack Deployment.StackName function gives you the currently deploying stack, which can be useful in naming, tagging, or accessing resources.

    let stack = pulumi.getStack();

    let stack = pulumi.getStack();

    stack = pulumi.get_stack()

    stack := ctx.Stack()

    var stack = Deployment.Instance.StackName;

    var stack = ctx.stackName();

    variables:
      stack: ${pulumi.stack}


    Stack references

    Stack references allow you to access the outputs of one stack from another stack. Inter-stack dependencies allow one stack to reference the outputs of another stack.

    To reference values from another stack, create an instance of the StackReference type using the fully qualified name of the stack as an input, and then read exported stack outputs by their name:

    const pulumi = require("@pulumi/pulumi");
    const other = new pulumi.StackReference("acmecorp/infra/other");
    const otherOutput = other.getOutput("x");

    import * as pulumi from "@pulumi/pulumi";
    const other = new pulumi.StackReference("acmecorp/infra/other");
    const otherOutput = other.getOutput("x");

    from pulumi import StackReference

    other = StackReference(f"acmecorp/infra/other")
    other_output = other.get_output("x");

    other, err := pulumi.NewStackReference(ctx, "acmecorp/infra/other", nil)
    if err != nil {
        return err
    }
    otherOutput := other.GetOutput(pulumi.String("x"))

    var other = new StackReference("acmecorp/infra/other");
    var otherOutput = other.GetOutput("x");

    var other = new StackReference("acmecorp/infra/other");
    var otherOutput = other.getOutput(Output.of("x"));

    resources:
      my-stack-reference:
        type: pulumi:pulumi:StackReference
        properties:
          name: acmecorp/infra/other

    variables:
      stack_output: ${my-stack-reference.outputs["x"]}


    Stack names must be fully qualified, including the organization, project, and stack name components, in the format <organization>/<project>/<stack>. For individual accounts, use your account name for the organization component.

    To expand on this further, imagine you need to define a cluster’s infrastructure in one project and consume it from another. Perhaps one project, infra, defines a Kubernetes cluster and another, services, deploys services into it. Let’s further imagine you are doing this across three distinct environments: production, staging, and testing. In that case, you will have six distinct stacks that pair up in the following ways:

    • mycompany/infra/production provides the cluster used by mycompany/services/production
    • mycompany/infra/staging provides the cluster used by mycompany/services/staging
    • mycompany/infra/testing provides the cluster used by mycompany/services/testing

    The way Pulumi programs communicate information for external consumption is by using stack exports. For example, your infrastructure stack might export the Kubernetes configuration information needed to deploy into a cluster:

    exports.kubeConfig = ... a cluster's output property ...;

    export const kubeConfig = ... a cluster's output property ...;

    pulumi.export("kubeConfig", ... a cluster's output property ...)

    ctx.Export("kubeConfig", /*...a cluster's output property...*/)

    class ClusterStack : Stack
    {
        [Output] public Output<string> KubeConfig { get; set; }

        public ClusterStack()
        {
            // ... a cluster is created ...

            this.KubeConfig = ... a cluster's output property ...
        }
    }

    ctx.export("kubeConfig", /*...a cluster's output property...*/);

    outputs:
      kubeConfig: ... # a cluster's output property


    The challenge in this scenario is that the services project needs to ingest this output during deployment so that it can connect to the Kubernetes cluster provisioned in its respective environment.

    The Pulumi programming model offers a way to do this with its StackReference resource type. For example:

    const k8s = require("@pulumi/kubernetes");
    const pulumi = require("@pulumi/pulumi");
    const env = pulumi.getStack();
    const infra = new pulumi.StackReference(`mycompany/infra/${env}`);
    const provider = new k8s.Provider("k8s", { kubeconfig: infra.getOutput("kubeConfig") });
    const service = new k8s.core.v1.Service(..., { provider: provider });

    import * as k8s from "@pulumi/kubernetes";
    import * as pulumi from "@pulumi/pulumi";
    const env = pulumi.getStack();
    const infra = new pulumi.StackReference(`mycompany/infra/${env}`);
    const provider = new k8s.Provider("k8s", { kubeconfig: infra.getOutput("kubeConfig") });
    const service = new k8s.core.v1.Service(..., { provider: provider });

    from pulumi import get_stack, ResourceOptions, StackReference
    from pulumi_kubernetes import Provider, core

    env = get_stack()
    infra = StackReference(f"mycompany/infra/{env}")
    provider = Provider("k8s", kubeconfig=infra.get_output("kubeConfig"))
    service = core.v1.Service(..., ResourceOptions(provider=provider))

    import (
      "fmt"

      "github.com/pulumi/pulumi/sdk/v3/go/pulumi"
    )

    func main() {
      pulumi.Run(func(ctx *pulumi.Context) error {
        slug := fmt.Sprintf("mycompany/infra/%v", ctx.Stack())
        stackRef, err := pulumi.NewStackReference(ctx, slug, nil)

        kubeConfig := stackRef.GetOutput(pulumi.String("kubeConfig"))
        // ...
        return nil
      }
    }

    using Pulumi;
    using Pulumi.Kubernetes.Core.V1;

    class AppStack : Stack
    {
        public AppStack()
        {
            var cluster = new StackReference($"mycompany/infra/{Deployment.Instance.StackName}");
            var kubeConfig = cluster.RequireOutput("KubeConfig").Apply(v => v.ToString());
            var provider = new Provider("k8s", new ProviderArgs { KubeConfig = kubeConfig });
            var options = new ComponentResourceOptions { Provider = provider };
            var service = new Service(..., ..., options);
        }
    }

    package myproject;

    import com.pulumi.Context;
    import com.pulumi.Exports;
    import com.pulumi.Pulumi;

    import com.pulumi.core.Output;
    import com.pulumi.kubernetes.Provider;
    import com.pulumi.kubernetes.ProviderArgs;
    import com.pulumi.kubernetes.core_v1.Service;
    import com.pulumi.kubernetes.core_v1.ServiceArgs;
    import com.pulumi.resources.ComponentResourceOptions;
    import com.pulumi.resources.StackReference;


    public class App {
        public static void main(String[] args) {
            Pulumi.run(App::stack);
        }

        public static void stack(Context ctx) {
            var cluster = new StackReference(String.format("mycompany/infra/%s", ctx.stackName()));
            var kubeconfig = cluster.requireOutput(Output.of("KubeConfig")).applyValue(String::valueOf);
            var provider = new Provider("k8s", ProviderArgs.builder().kubeconfig(kubeconfig).build());
            var options = ComponentResourceOptions.builder()
                .provider(provider)
                .build();
            var service = new Service("app-service", ServiceArgs.builder()
                ...
                .build(), options);
        }
    }

    variables:
      kubeConfig: ${my-stack-reference.outputs["KubeConfig"]}
    resources:
      my-stack-reference:
        type: pulumi:pulumi:StackReference
        properties:
          name: mycompany/infra/${pulumi.stack}
      provider:
        type: pulumi:providers:kubernetes
        properties:
          kubeConfig: kubeConfig
      service:
        type: some:resource:type
        properties: ...
        options:
          provider: ${provider}


    The StackReference constructor takes as input a string of the form <organization>/<project>/<stack>, and lets you access the outputs of that stack.

    In the above example, you construct a stack reference to a specific stack in this project which has the same name as your current stack (i.e. when deploying the “staging” stack of the above program, you reference the “staging” stack) from the infra project. Once you have that resource, you can fetch the kubeConfig output variable with the getOutput function. From that point onwards, Pulumi understands the inter-stack dependency for scenarios like cascading updates.

    Reading outputs from stack references

    Stack references support two ways of reading outputs from the referenced stack:

    • getOutput returns an Output that provides gated access to the output value. The output value can be accessed and transformed with methods like Output.apply. This is useful when the output is used as an input to another resource.
    • getOutputDetails returns an OutputDetails object that provides direct access to the output value. This is useful when you want to process the output directly in your code.

    As a demonstration of getOutput, suppose that your referenced stack exports a privateIp output. You want to incorporate the IP address into the name of an S3 bucket object containing logs from that machine.

    const infra = new pulumi.StackReference(...);
    const ip = infra.getOutput("privateIp");
    const logKey = ip.apply(ip => `logs/${ip}.log`);
    const logFile = new aws.s3.BucketObject("log", {
        // ...
        key: logKey
    });

    const infra: StackReference = new pulumi.StackReference(...);
    const ip: Output<any> = infra.getOutput("privateIp");
    const logKey: Output<string> = ip.apply(ip => `logs/${ip}.log`);
    const logFile: aws.s3.BucketObject = new aws.s3.BucketObject("log", {
        // ...
        key: logKey
    });

    infra = StackReference(...)
    ip = infra.get_output("privateIp")
    log_key = ip.apply(lambda ip: f"logs/{ip}.log")
    log_file = aws.s3.BucketObject("log", {
        # ...
        key: log_key
    })

    infra, err := pulumi.NewStackReference(ctx, ...)
    if err != nil {
        return err
    }
    ip := infra.GetOutput("privateIp")
    logKey := ip.ApplyT(func(ip string) string {
        return fmt.Sprintf("logs/%s.log", ip)
    }).(StringOutput)
    logFile := s3.NewBucketObject(ctx, "log", &s3.BucketObjectArgs{
        // ...
        Key: logKey,
    })

    var infra = new StackReference(...);
    var ip = infra.GetOutput("privateIp");
    var logKey = ip.Apply(ip => $"logs/{ip}.log");
    var logFile = new Aws.S3.BucketObject("log", new Aws.S3.BucketObjectArgs
    {
        // ...
        Key = logKey,
    });

    StackReference infra = new StackReference(...);
    Output<String> ip = infra.getOutput("privateIp");
    Output<String> logKey = ip.apply(ip -> String.format("logs/%s.log", ip));
    BucketObject logFile = new BucketObject("log", new BucketObjectArgs.Builder()
        .key(logKey)
        .build());


    On the other hand, as an example of using getOutputDetails, suppose that your referenced stack creates a VPC and exports a list of public subnets as a JSON-serialized string, and you want to add a bastion host to each subnet. With getOutputDetails, this would look something like this:

    const infra = new pulumi.StackReference(...);
    const subnetsJSON = await infra.getOutputDetails("subnets");
    const subnets = JSON.parse(subnetsJSON.value);
    for (let i = 0; i < subnets.length; i++) {
        const subnet = subnets[i];
        const host = new aws.ec2.Instance(`bastion-${i}`, {
            // ...
            subnetId: subnet.id,
        });
        // ...
    }


    Note that your Pulumi program must export a top-level async function to be able to use the await operator.

    export = async () => {
        // ...
    }


    See Javascript Entrypoint for more information.

    const infra: StackReference = new pulumi.StackReference(...);
    const subnetsJSON: StackReferenceOutputDetails = await infra.getOutputDetails("subnets");
    const subnets = JSON.parse(subnetsJSON.value);
    for (let i = 0; i < subnets.length; i++) {
        const subnet = subnets[i];
        const host = new aws.ec2.Instance(`bastion-${i}`, {
            // ...
            subnetId: subnet.id,
        });
        // ...
    }


    Note that your Pulumi program must export a top-level async function to be able to use the await operator.

    export = async () => {
        // ...
    }


    See Javascript Entrypoint for more information.

    This functionality is not currently supported in Python. Progress is tracked on pulumi/pulumi#12172 if you need this functionality.
    infra, err := pulumi.NewStackReference(ctx, ...)
    if err != nil {
        return err
    }
    subnetsJSON, err := infra.GetOutputDetails("subnets")
    if err != nil {
        return err
    }
    var subnets []struct{ ID string `json:"id"` }
    if err := json.Unmarshal([]byte(subnetsJSON.Value.(string)), &subnets); err != nil {
        return err
    }

    for i, subnet := range subnets {
        host, err := ec2.NewInstance(ctx, fmt.Sprintf("bastion-%d", i), &ec2.InstanceArgs{
            // ...
            SubnetId: pulumi.String(subnet.ID),
        })
        if err != nil {
            return err
        }
        // ...
    }

    var infra = new StackReference(...);
    var subnetsJSON = await infra.GetOutputDetailsAsync("subnets");
    var subnets = JsonConvert.DeserializeObject<Subnet[]>((string)subnetsJSON.Value);
    for (int i = 0; i < subnets.Length; i++) {
        var subnet = subnets[i];
        var host = new Aws.Ec2.Instance($"bastion-{i}", new Aws.Ec2.InstanceArgs
        {
            // ...
            SubnetId = subnet.Id,
        });
        // ...
    }


    Note that your Pulumi program must be inside an async function to be able to use the await operator.

    return await Deployment.RunAsync(async () =>
    {
        // ...
    });

    StackReferenceOutputDetails subnetsJSON = infra.outputDetails("subnets");
    infra.outputDetailsAsync("subnets").thenAccept(subnetsJSON -> {
        Subnet[] subnets = new Gson().fromJson((String)subnetsJSON.getValue().get(), Subnet[].class);
        for (int i = 0; i < subnets.length; i++) {
            Subnet subnet = subnets[i];
            Instance host = new Instance(String.format("bastion-%d", i), new InstanceArgs.Builder()
                // ...
                .subnetId(subnet.getId())
                .build());
            // ...
        }
    })


    Import and export a stack deployment

    A stack can be exported to see the raw data associated with the stack. This is useful when manual changes need to be applied to the stack due to changes made in the target cloud platform that Pulumi is not aware of. The modified stack can then be imported to set the current state of the stack to the new values.

    This is a powerful capability that subverts the usual way that Pulumi manages resources and ensures immutable and repeatable infrastructure deployments. Importing an incorrect stack specification could lead to the orphaning of cloud resources or the inability to make future updates to the stack. Use care when using the import and export capabilities.
    $ pulumi stack export --file stack.json

    $ pulumi stack import --file stack.json


    Destroy a stack

    Before deleting a stack, if the stack still has resources associated with it, they must first be deleted via pulumi destroy. This command uses the latest configuration values, rather than the ones that were last used when the program was deployed.

    There are scenarios when pulumi destroy may fail to delete resources as expected due to dependencies, permissions, or the resources being in a locked or protected state. For detailed steps on how to troubleshoot and resolve these issues, refer to our troubleshooting guide.

    Delete a stack

    To delete a stack with no resources, run pulumi stack rm. Removing the stack will remove all stack history from pulumi.com and will delete the stack configuration file Pulumi.<stack-name>.yaml.

    To force the deletion of a stack that still contains resources—potentially orphaning them—use pulumi stack rm --force.

      PulumiUP 2024. Watch On Demand.
