Pulumi YAML reference

    Pulumi programs can be defined in many languages, and the Pulumi YAML dialect offers an additional language for authoring Pulumi programs.

    The Pulumi YAML provider supports programs written in YAML or JSON. In both cases, the programs (.yaml or .json files) follow a simple schema, including four top level sections:

    PropertyTypeRequiredExpressionDescription
    configconfig optionsNoNoConfig specifies the Pulumi config inputs to the deployment.
    resourcesmap[string]ResourceNoNoResources declares the Pulumi resources that will be deployed and managed by the program
    variablesmap[string]ExpressionNoYesVariables specifies intermediate values of the program, the values of variables are expressions that can be re-used.
    outputsmap[string]ExpressionNoYesOutputs specifies the Pulumi stack outputs of the program and how they are computed from the resources is a value of the appropriate type for the template to use if no value is specified.

    In many locations within this schema, values may be expressions which computed a value based on the config, variables, or outputs of resources. These expressions can be provided in two ways:

    • If an object is provided as a value, and has a key that has the prefix fn::, the object is treated as an expression, and the expression will be resolved to a new value that will be used in place of the object.
    • Any string value is interpreted as an interpolation, with ${...} being replaced by evaluating the expression in the ....

    The supported expression forms for each of these is detailed below.

    Config

    config is a map of config property keys to either values or structured declarations (see here).

    In beta, Pulumi YAML projects used the configuration key. This will eventually be deprecated; switching from configuration to config will not break existing projects.

    The value of configuration is an object whose keys are logical names by which the config input will be referenced in expressions within the program, and whose values are elements of the schema below. Each item in this object represents an independent config input. Either type or default is required.

    PropertyTypeRequiredExpressionDescription
    typestringNoNoType is the (required) data type for the parameter. It can be one of: String, Number, List<Number>, or List<String>.
    defaultanyNoNoDefault is a value of the appropriate type for the template to use if no value is specified.
    secretboolNoNoSecret specifies if the config value should be encrypted as a secret.

    Resources

    The value of resources is an object whose keys are logical resource names by which the resource will be referenced in expressions within the program, and whose values which are elements of the schema below. Each item in this object represents a resource which will be managed by the Pulumi program.

    PropertyTypeRequiredExpressionsDescription
    typestringYesNoType is the Pulumi type token for this resource.
    defaultProviderboolNoNoDefaultProvider specifies if a provider should be used for resources without an explicit one set. Set only on provider resources.
    propertiesmap[string]ExpressionNoYesProperties contains the primary resource-specific keys and values to initialize the resource state.
    optionsResource OptionsNoNoOptions contains all resource options supported by Pulumi.
    getResource GetterNoYesA getter function for the resource. Supplying get is mutually exclusive to properties.

    Resource Options

    The value of the options property of a Resource is an object whose keys are resource option names and whose values are elements of the schema below. No resource options are required.

    The dependsOn, parent, provider, and providers values permit expressions which must use interpolation syntax to reference resources by name. For example:

        options:
          provider: ${myEksProvider}
          providers:
            aws: ${myAwsProvider}
          dependsOn:
            - ${otherResource}
          parent: ${someParentResource}

    PropertyTypeDescription
    additionalSecretOutputsstring[]AdditionalSecretOutputs specifies properties that must be encrypted as secrets
    aliasesstring[]Aliases specifies names that this resource used to have, so that renaming or refactoring doesn’t replace it
    customTimeoutsCustom TimeoutCustomTimeouts overrides the default retry/timeout behavior for resource provisioning
    deleteBeforeReplaceboolDeleteBeforeReplace overrides the default create-before-delete behavior when replacing
    dependsOnExpression[]DependsOn makes this resource explicitly depend on another resource, by name, so that it won’t be created before the dependent finishes being created (and the reverse for destruction). Normally, Pulumi automatically tracks implicit dependencies through inputs/outputs, but this can be used when dependencies aren’t captured purely from input/output edges.
    ignoreChangesstring[]IgnoreChanges declares that changes to certain properties should be ignored during diffing
    importstringImport adopts an existing resource from your cloud account under the control of Pulumi
    parentExpressionParent specifies a parent for the resource
    protectboolProtect prevents accidental deletion of a resource
    providerExpressionProvider specifies an explicitly configured provider, instead of using the default global provider
    providersmap[string]ExpressionMap of providers for a resource and its children.
    versionstringVersion specifies a provider plugin version that should be used when operating on a resource
    pluginDownloadURLstringPluginDownloadURL specifies a provider plugin download URL
    replaceOnChangesstring[]ReplaceOnChanges specifies if changes to certain properties on a resource should force replacement instead of an in-place update.
    retainOnDeleteboolRetainOnDelete causes a resource to be preserved in the cloud even when it is deleted from the Pulumi state.

    Resource Getter

    Supplying a get key turns the resource declaration into a Getter Function.

    PropertyTypeRequiredDescription
    idstringYesThe ID of the resource to import
    statemap[string]ExpressionNoKnown properties (input & output) of the resource. This assists the provider in figuring out the correct resource.

    Custom Timeout

    The optional customTimeouts property of a resource is an object of the following schema:

    PropertyTypeRequiredExpressionDescription
    createstringNoNoCreate is the custom timeout for create operations.
    deletestringNoNoDelete is the custom timeout for delete operations.
    updatestringNoNoUpdate is the custom timeout for update operations.

    Providers and provider versions

    There are at least two reasons to explicitly define providers in YAML, or explicitly set their versions while creating resources.

    1. Using explicit versions enables pinning the dependencies used, a technique used to improve build reliability.
    2. Using explicit providers enables controlling the options for providers used by each resource, as described in Unlock Programmatic Control by Disabling Default Providers.

    If a specific provider version is necessary, we prefer the approaches in the order described here.

    Default provider

    Declaring a default provider simplifies configuring a provider version across all resources for that provider.

    To configure the default provider instance for all resources for that provider’s name, use the resources section to declare a provider resource.

    For the type property, prefix the name of the provider with pulumi:providers, for example, pulumi:providers:aws. Setting the defaultProvider property to true, defined at the same level as type, configures this as a default provider.

    resources:
      aws-provider:
        type: pulumi:providers:aws
        defaultProvider: true
        options:
          version: 6.45.0
      my-bucket:
        type: aws:s3:Bucket


    In this example the my-bucket resource, and any other AWS resources, uses the default AWS provider version 6.45.0.

    Only one provider of a given type can be declared as the default provider.

    Explicit provider

    To declare an explicit provider instance for specific resources, declare a provider resource in the resources section. For the type property, prefix the name of the provider with pulumi:providers.

    resources:
      provider:
        type: pulumi:providers:azure
        options:
          version: 5.1.0


    The provider instance can than be used as described in section Resource Options by setting the provider option:

    resources:
      provider:
        type: pulumi:providers:azure
        options:
          version: 5.1.0
      rg:
        type: azure:core:ResourceGroup
        properties:
          location: WestEurope
        options:
          provider: ${provider}


    Explicit providers take precedence over default providers.

    Resource version

    To declare a resource with a specific provider version use the version option as described in Resource Options:

    resources:
      something:
        type: aws:s3:Bucket
        properties:
          ...
        options:
          version: 5.6.0


    Third party providers

    Third party providers may require a pluginDownloadURL option for Pulumi to acquire the provider plugin. The publisher of that provider should provide this URL, following our guide for Authoring & Publishing.

    All of the above examples setting a version with a default provider, explicit provider, or on individual resources may be combined with the pluginDownloadURL option to use a third party provider.

    This declares one of Pulumi’s own providers as a default provider, setting an explicit pluginDownloadURL.

    resources:
      aws-provider:
        type: pulumi:providers:aws
        defaultProvider: true
        options:
          version: 6.45.0
          pluginDownloadURL: github://api.github.com/pulumi
      my-bucket:
        type: aws:s3:Bucket


    Outputs and Stack References

    The value of outputs is an object whose keys are the logical names of the outputs that are available from outside the Pulumi stack (via pulumi stack output), and whose values are potentially computed expressions that resolve to the values of the desired outputs.

    outputs:
      outputName: ${resource.id}


    Stack references can be used to access the outputs of one stack from within another stack. A stack reference requires the fully qualified name of the stack as an argument in the format of <organization>/<project>/<stack>.

    resources:
      reference:
        type: pulumi:pulumi:StackReference
        properties:
          name: org/project/stack

    outputs:
      secondOutputName: ${reference.outputs["outputName"]}


    The above output will have the value of the outputName output from the stack org/project/stack.

    Expressions

    Expressions can be used in several contexts:

    • the properties of properties of resources
    • the properties of options of resources that take references to other resources: parent, dependsOn, provider, and providers
    • the values of variables and outputs
    • some or all values provided to built-in functions, as specified below

    Generally speaking, most values permit an expression and exceptions will be documented as not permitting an expression, as above.

    In these contexts, any JSON/YAML value may be provided. If that value is a string, it is interpolated. If that value is an object, and the object has a key with a prefix of fn::, it is evaluated as an expression.

    Interpolation

    In expression locations, strings are evaluated as interpolations and any nested ${...} expressions within the string value are replaced by the value of the expression .... The syntax of expressions within interpolations permits property access only.

    To use ${} in a string literal, escape $ with $$ like so:

    variables:
      plainString: $${value}


    A string like Hello, ${foo} will convert the expression foo to a string.

    If a string contains only an ${...} expression, it’s considered a substitution.

    Property Access

    Within an expression denoted by ${...} property access is permitted according to the forms below. Config, variables, and resource keys all exist in a single namespace, and in the examples, root or equivalent must be the name of one of these items, and it must be valid to access the foo property of that item if it’s a map or object, or if it’s an array, the index must be valid.

    • ${root}
    • ${root.foo}
    • ${root["foo"]}
    • ${root.bar.quux}
    • ${root["bar"].quux}
    • ${root["bar"]["quux"]}
    • ${root[0]}
    • ${root[100]}
    • ${root[0].foo}
    • ${root[0][1].foo}
    • ${root.foo.items[0].bar[1]}
    • ${root["key with \"escaped\" quotes"]}
    • ${root["key with a ."]}
    • ${["root key with \"escaped\" quotes"].foo}
    • ${["root key with a ."][100]}

    We have not discussed types until now, but implicitly every expression has a type, such as number, string, map, array, or even resource. When interpolated, these values must become strings, otherwise they are substituted in. Additionally:

    • maps must have string keys and expression values
    • arrays have non-negative integer indices and expression values
    • property access on a Resource retrieves outputs

    Substitution

    Expressions denoted by ${...} are only converted to strings when interpolated into a string with surrounding text. If a resource property takes a list or a map for example, that can be provided by a variable whose value can be substituted in. In the example below, the httpPort variable is used to reduce repetition in the two Kubernetes Service resources.

    name: kubernetes-port-example
    variables:
      httpPort:
        protocol: TCP
        port: 80
        targetPort: 8000
    resources:
      serviceOne:
        type: kubernetes:core/v1:Service
        properties:
          spec:
            selector:
              app: "MyApp"
            ports:
              - ${httpPort}
      serviceTwo:
        type: kubernetes:core/v1:Service
        properties:
          spec:
            selector:
              app: "OtherApp"
            ports:
              - ${httpPort}


    The last two lines are equivalent as if the variable were substituted for its value:

            ports:
              - protocol: TCP
                port: 80
                targetPort: 8000


    Built-in Functions

    In any expression location, an object containing a single key beginning with fn:: calls a built-in function.

    fn::toBase64

    Converts a UTF-8 string into a Base64 encoded string using the standard encoding.

    variables:
      greeting:
        fn::toBase64: "Hello, world!"


    The expression ${greeting} will return SGVsbG8sIHdvcmxkIQ==

    fn::fromBase64

    Converts a Base64 encoded string into a UTF-8 string. This will fail if the result is not a valid UTF-8 string

    variables:
      greeting:
        fn::fromBase64: SGVsbG8sIFdvcmxkIQ==


    The expression ${greeting} will return Hello, World!

    fn::toJSON

    Converts a value into its JSON representation.

    variables:
      item:
        fn::toJSON:
          key1: value1
          key2: 123


    The expression ${item} will return a JSON value { "key1": "value1", "key2": 123 }.

    fn::invoke

    Calls a function from a package and returns either the whole object or a single field if given the return property. This can be any of the functions in the registry providers as well as functions found in the pulumi-std package that includes math functions such as sum and abs, logic functions such as anytrue, and string functions such as split.

    The schema is:

    PropertyTypeRequiredExpressionDescription
    functionstringYesNoName of a function to call.
    argumentsmap[string]ExpressionYesYesArguments to pass to the expression, each key is a named argument.
    optionsInvoke OptionsNoNoOptions for the provider calling the function.
    returnstringNoNoReturn the value of the field with this name.

    Example calling the getAmi function in the AWS provider package:

    variables:
      AmazonLinuxAmi:
        fn::invoke:
          function: aws:getAmi
          arguments:
            filters:
              - name: name
                values: ["amzn-ami-hvm-*-x86_64-ebs"]
            owners: ["137112412989"]
            mostRecent: true
          options:
            version: 5.9.0
          return: id


    The expression ${AmazonLinuxAmi} will return the AMI ID returned from the aws:getAmi function.

    Example calling the sum function in the pulumi-std provider package to subtract 255 from ${route53Weight}:

    variables:
      route53Weight: 400
      modifiedWeight:
        fn::invoke:
          function: std:sum
          arguments:
            input:
              - ${route53Weight}
              - -255
          return: result


    The expression ${modifiedWeight} will return 145 in this case.

    Invoke Options

    The value of the options property of an fn::invoke is an object with the following properties.

    The parent and provider values permit expressions which must use interpolation syntax to reference resources by name. For example:

        options:
          provider: ${myEksProvider}
          parent: ${someParentResource}

    PropertyTypeDescription
    parentExpressionParent specifies a parent for the resource
    providerExpressionProvider specifies an explicitly configured provider, instead of using the default global provider
    versionstringVersion specifies a provider plugin version that should be used when operating on a resource
    pluginDownloadURLstringVersion specifies a URL that should be used when to download the provider plugin
    fn::join

    Joins strings together separated by a delimiter. Arguments are passed as a list, with the first item being the delimiter, and the second item a list of expressions to concatenate.

    variables:
        banana:
            fn::join:
                - 'NaN'
                - - Ba
                  - a


    The expression ${banana} will have the value "BaNaNa".

    fn::split

    Splits a string on a delimiter. Arguments are passed as a list, with the first item being the delimiter, and the second item the string to split.

    variables:
        fruits:
            fn::split:
                - ", "
                - "apple, orange, banana"


    The expression ${fruits} will be a list containing the values ["apple", "orange", "banana"].

    fn::select

    Selects one of several options given an index. Arguments are passed as a list, with the first item being the index, 0-based, and the second item a list of expressions to select from.

    variables:
        policyVersion:
            fn::select:
                - 1
                - - v1
                  - v1.1
                  - v2.0


    The expression ${policyVersion} will have the value v1.1.

    fn::*Asset and fn::*Archive

    Assets and Archives are intrinsic types to Pulumi, like strings and numbers, and some resources may take these as inputs or return them as outputs. The built-ins create each kind of asset or archive. Each takes all take a single string value.

    Built-InArgument TypeDescription
    fn::fileAssetstringThe contents of the asset are read from a file on disk.
    fn::stringAssetstringThe contents of the asset are read from a string in memory.
    fn::remoteAssetstringThe contents of the asset are read from an http, https or file URI.
    fn::fileArchivestringThe contents of the archive are read from either a folder on disk or a file on disk in one of the supported formats: .tar, .tgz, .tar.gz, .zip or .jar.
    fn::remoteArchivestringThe contents of the asset are read from an http, https or file URI, which must produce an archive of one of the same supported types as FileArchive.
    fn::assetArchivemapThe contents of the archive are read from a map of either Asset or Archive objects, one file or folder respectively per entry in the map.
    variables:
      aFile:
        fn::fileAsset: ./file.txt
      aString:
        fn::stringAsset: Hello, world!
      aRemoteAsset:
        fn::remoteAsset: http://worldclockapi.com/api/json/est/now

      aFileArchive:
        fn::fileArchive: ./file.zip
      aRemoteArchive:
        fn::remoteArchive: http://example.com/file.zip
      anAssetArchive:
        fn::assetArchive:
          file:
            fn::stringAsset: Hello, world!
          folder:
            fn::fileArchive: ./folder

    fn::secret

    Constructs a Secret from an existing value.

    variables:
      secret:
        fn::secret:
          fn::invoke:
            function: my:pkg:GetSecretValue

    fn::readFile

    Reads a file from disk and returns the contents as a string, must be utf-8. This function has special rules for its behavior.

    variables:
      someText:
        fn::readFile: ./README.md


    Any subpath of the Pulumi project directory is allowed, whether it is absolute, relative, constant, or an expression:

    • fn::readFile: ./README.md, a relative subpath
    • fn::readFile: ${pulumi.cwd}/example.txt, an absolute subpath
    • fn::readFile: /opt/project-dir/example.json, an absolute subpath if the program is in /opt/project-dir

    Absolute paths to any location are allowed if they are constants:

    • fn::readFile: /etc/lsb-release
    • fn::readFile: /usr/share/nginx/html
    • fn::readFile: /var/run/secrets/kubernetes.io/serviceaccount/token

    Relative paths that escape the project directory and absolute paths that are non-constant are forbidden to prevent path traversals.

    • fn::readFile: ../../etc/shadow, a relative path that escapes the project
    • fn::readFile: ${pulumi.cwd}/../../.ssh/id_rsa.pub, an expression that returns an absolute path that escapes the project

    Built-in variables

    Built-in variables accessible within any Pulumi YAML program.

    pulumi

    The built-in pulumi variable contains three properties, which can be useful for retrieving information about your current workspace.

        variables:
          cwd: ${pulumi.cwd}
          project: ${pulumi.project}
          stack: ${pulumi.stack}

    • ${pulumi.cwd} retrieves the current working directory
    • ${pulumi.project} retrieves the current project
    • ${pulumi.stack} retrieves the current stack
      PulumiUP 2024. Watch On Demand.
