Reference Google Cloud Resources Across Stacks

In this tutorial, you will learn how to work with stack outputs, specifically how to export values from a stack and how to reference those values from another stack. You will do this by creating simple Google Cloud Storage Bucket and custom IAM Role resources in one stack. You will then create a Bucket Object resource in a second project/stack that will upload a file to the bucket created in the first stack.

In this tutorial, you'll learn:

How to create a stack output
How to view the stack output
How to reference the output from a different stack

Prerequisites:

The Pulumi CLI
A Pulumi Cloud account and access token
A Google Cloud account
The Google Cloud CLI
Familiarity with one of Pulumi’s supported languages

Understanding stack outputs

Every Pulumi resource has outputs, which are properties of that resource whose values are generated during deployment. You can export these values as stack outputs, and they can be used for important values like resource IDs, computed IP addresses, and DNS names.

These outputs are shown during an update, can be easily retrieved with the Pulumi CLI, and are displayed in Pulumi Cloud. For the purposes of this tutorial, you will primarily be working from the CLI.

Create a new project

# Example using Python
$ mkdir pulumi-tutorial-gcp
$ cd pulumi-tutorial-gcp
$ pulumi new gcp-python

Then replace the default code with the following code snippet to scaffold your project with the required imports and overall program structure:

"use strict";
const pulumi = require("@pulumi/pulumi");
const gcp = require("@pulumi/gcp");

const bucket = new gcp.storage.Bucket("bucket", {
    location: "US",
    forceDestroy: true,
});

const role = new gcp.projects.IAMCustomRole("role", {
    roleId: "bucketViewerRole",
    title: "Bucket Viewer Role",
    permissions: ["storage.objects.get", "storage.objects.list"],
    stage: "GA",
});

const bucketViewerRoleAssignment = new gcp.storage.BucketIAMMember("bucketViewerRoleAssignment", {
    bucket: bucket.name,
    role: role.name,
    member: "allAuthenticatedUsers",
});

import * as pulumi from "@pulumi/pulumi";
import * as gcp from "@pulumi/gcp";

const bucket = new gcp.storage.Bucket("bucket", {
    location: "US",
    forceDestroy: true,
});

const role = new gcp.projects.IAMCustomRole("role", {
    roleId: "bucketViewerRole",
    title: "Bucket Viewer Role",
    permissions: ["storage.objects.get", "storage.objects.list"],
    stage: "GA",
});

const bucketViewerRoleAssignment = new gcp.storage.BucketIAMMember("bucketViewerRoleAssignment", {
    bucket: bucket.name,
    role: role.name,
    member: "allAuthenticatedUsers",
});

import pulumi
from pulumi_gcp import storage, projects

role = projects.IAMCustomRole(
    "bucketViewerRole",
    role_id="bucketViewerRole",
    title="Bucket Viewer Role",
    permissions=[
        "storage.objects.get",
        "storage.objects.list"
    ],
    stage="GA"
)

bucket = storage.Bucket(
    "my-bucket",
    location="US",
    force_destroy=True
)

bucket_iam_member = storage.BucketIAMMember(
    "bucketViewerRoleAssignment",
    bucket=bucket.name,
    role=role.name,
    member="allAuthenticatedUsers"
)

package main

import (
	"fmt"

	"github.com/pulumi/pulumi-gcp/sdk/v8/go/gcp/projects"
	"github.com/pulumi/pulumi-gcp/sdk/v8/go/gcp/storage"
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		bucket, err := storage.NewBucket(ctx, "bucket", &storage.BucketArgs{
			Location:     pulumi.String("US"),
			ForceDestroy: pulumi.Bool(true),
		})
		if err != nil {
			return err
		}

		role, err := projects.NewIAMCustomRole(ctx, "role", &projects.IAMCustomRoleArgs{
			RoleId: pulumi.String("bucketViewerRole"),
			Title:  pulumi.String("Bucket Viewer Role"),
			Permissions: pulumi.StringArray{
				pulumi.String("storage.objects.get"),
				pulumi.String("storage.objects.list"),
			},
			Stage: pulumi.String("GA"),
		})
		if err != nil {
			return err
		}

		_, err = storage.NewBucketIAMMember(ctx, "bucketViewerRoleAssignment", &storage.BucketIAMMemberArgs{
			Bucket: bucket.Name,
			Role:   role.Name,
			Member: pulumi.String("allAuthenticatedUsers"),
		})
		if err != nil {
			return err
		}

		return nil
	})
}

using System.Collections.Generic;
using System.Linq;
using Pulumi;
using Gcp = Pulumi.Gcp;

return await Deployment.RunAsync(() =>
{
    var bucket = new Gcp.Storage.Bucket("bucket", new()
    {
        Location = "US",
        ForceDestroy = true,
    });

    var role = new Gcp.Projects.IAMCustomRole("role", new()
    {
        RoleId = "bucketViewerRole",
        Title = "Bucket Viewer Role",
        Permissions = new[]
        {
            "storage.objects.get",
            "storage.objects.list",
        },
        Stage = "GA",
    });

    var bucketViewerRoleAssignment = new Gcp.Storage.BucketIAMMember("bucketViewerRoleAssignment", new()
    {
        Bucket = bucket.Name,
        Role = role.Name,
        Member = "allAuthenticatedUsers",
    });

});

name: gcp-storage-bucket-object-yaml
description: An example that deploys a storage bucket and uploads a file on Google Cloud.
runtime: yaml

resources:
  role:
    type: gcp:projects:IAMCustomRole
    properties:
      roleId: bucketViewerRole
      title: Bucket Viewer Role
      permissions:
        - storage.objects.get
        - storage.objects.list
      stage: GA

  bucket:
    type: gcp:storage:Bucket
    properties:
      location: US
      forceDestroy: true

  bucketViewerRoleAssignment:
    type: gcp:storage:BucketIAMMember
    properties:
      bucket: ${bucket.name}
      role: ${role.name}
      member: allAuthenticatedUsers

This baseline code defines the following on your behalf:

Export resource values

As mentioned in the Creating Resources on Google Cloud tutorial, every resource has various properties. For any resources that you define in your Pulumi projects, you can export the values of its properties from your program as outputs. You can view a list of available properties that can be exported by referring to the resource properties section of a particular resource’s API documentation (e.g. Bucket properties). The export syntax is as follows:

exports.<output-name> = <output-value>;

export const <output-name> = <output-value>;

pulumi.export("<output-name>", <output-value>)

ctx.Export("<output-name>", <output-value>)

return await Pulumi.Deployment.RunAsync(() =>
{

    return new Dictionary<string, object?>
    {
        ["<output-name>"] = <output-value>
    };

});

outputs:
  <output-name>: ${<output-value>}

When defining these exports, you’ll need to provide two arguments:

Argument	Description
Output name	This is the name you will use as the identifier of your output value
Output value	This is the actual value of your output

To demonstrate how this works, let’s export the name of your IAM Role. By referring to the documentation, you can see that the name of the IAM Role can be referenced via its role ID property, so update your code to reflect that as shown below:

"use strict";
const pulumi = require("@pulumi/pulumi");
const gcp = require("@pulumi/gcp");

const bucket = new gcp.storage.Bucket("bucket", {
    location: "US",
    forceDestroy: true,
});

const role = new gcp.projects.IAMCustomRole("role", {
    roleId: "bucketViewerRole",
    title: "Bucket Viewer Role",
    permissions: ["storage.objects.get", "storage.objects.list"],
    stage: "GA",
});

const bucketViewerRoleAssignment = new gcp.storage.BucketIAMMember("bucketViewerRoleAssignment", {
    bucket: bucket.name,
    role: role.name,
    member: "allAuthenticatedUsers",
});

exports.roleName = role.roleId;

import * as pulumi from "@pulumi/pulumi";
import * as gcp from "@pulumi/gcp";

const bucket = new gcp.storage.Bucket("bucket", {
    location: "US",
    forceDestroy: true,
});

const role = new gcp.projects.IAMCustomRole("role", {
    roleId: "bucketViewerRole",
    title: "Bucket Viewer Role",
    permissions: ["storage.objects.get", "storage.objects.list"],
    stage: "GA",
});

const bucketViewerRoleAssignment = new gcp.storage.BucketIAMMember("bucketViewerRoleAssignment", {
    bucket: bucket.name,
    role: role.name,
    member: "allAuthenticatedUsers",
});

export const roleName1 = role.roleId;

import pulumi
from pulumi_gcp import storage, projects

role = projects.IAMCustomRole(
    "bucketViewerRole",
    role_id="bucketViewerRole",
    title="Bucket Viewer Role",
    permissions=[
        "storage.objects.get",
        "storage.objects.list"
    ],
    stage="GA"
)

bucket = storage.Bucket(
    "my-bucket",
    location="US",
    force_destroy=True
)

bucket_iam_member = storage.BucketIAMMember(
    "bucketViewerRoleAssignment",
    bucket=bucket.name,
    role=role.name,
    member="allAuthenticatedUsers"
)

pulumi.export("roleName", role.role_id)

package main

import (
	"fmt"

	"github.com/pulumi/pulumi-gcp/sdk/v8/go/gcp/projects"
	"github.com/pulumi/pulumi-gcp/sdk/v8/go/gcp/storage"
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		bucket, err := storage.NewBucket(ctx, "bucket", &storage.BucketArgs{
			Location:     pulumi.String("US"),
			ForceDestroy: pulumi.Bool(true),
		})
		if err != nil {
			return err
		}

		role, err := projects.NewIAMCustomRole(ctx, "role", &projects.IAMCustomRoleArgs{
			RoleId: pulumi.String("bucketViewerRole"),
			Title:  pulumi.String("Bucket Viewer Role"),
			Permissions: pulumi.StringArray{
				pulumi.String("storage.objects.get"),
				pulumi.String("storage.objects.list"),
			},
			Stage: pulumi.String("GA"),
		})
		if err != nil {
			return err
		}

		_, err = storage.NewBucketIAMMember(ctx, "bucketViewerRoleAssignment", &storage.BucketIAMMemberArgs{
			Bucket: bucket.Name,
			Role:   role.Name,
			Member: pulumi.String("allAuthenticatedUsers"),
		})
		if err != nil {
			return err
		}

		ctx.Export("roleName", role.RoleId)

		return nil
	})
}

using System.Collections.Generic;
using System.Linq;
using Pulumi;
using Gcp = Pulumi.Gcp;

return await Deployment.RunAsync(() =>
{
    var bucket = new Gcp.Storage.Bucket("bucket", new()
    {
        Location = "US",
        ForceDestroy = true,
    });

    var role = new Gcp.Projects.IAMCustomRole("role", new()
    {
        RoleId = "bucketViewerRole",
        Title = "Bucket Viewer Role",
        Permissions = new[]
        {
            "storage.objects.get",
            "storage.objects.list",
        },
        Stage = "GA",
    });

    var bucketViewerRoleAssignment = new Gcp.Storage.BucketIAMMember("bucketViewerRoleAssignment", new()
    {
        Bucket = bucket.Name,
        Role = role.Name,
        Member = "allAuthenticatedUsers",
    });

    return new Dictionary<string, object?>
    {
        ["roleName"] = role.RoleId,
    };
});

name: gcp-storage-bucket-object-yaml
description: An example that deploys a storage bucket and uploads a file on Google Cloud.
runtime: yaml

resources:
  role:
    type: gcp:projects:IAMCustomRole
    properties:
      roleId: bucketViewerRole
      title: Bucket Viewer Role
      permissions:
        - storage.objects.get
        - storage.objects.list
      stage: GA

  bucket:
    type: gcp:storage:Bucket
    properties:
      location: US
      forceDestroy: true

  bucketViewerRoleAssignment:
    type: gcp:storage:BucketIAMMember
    properties:
      bucket: ${bucket.name}
      role: ${role.name}
      member: allAuthenticatedUsers

outputs:
  roleName: ${role.name}

Deploy your resources

Now save your file and run the pulumi up command to preview and deploy the resources you’ve just defined in your project.

$ pulumi up -y
Previewing update (stack-outputs)

     Type                           Name               Plan
 +   pulumi:pulumi:Stack            gcp-stack-outputs  create
 +   ├─ gcp:projects:IAMCustomRole  bucketViewerRole   create
 +   └─ gcp:storage:Bucket          my-bucket          create

Outputs:
    roleName: output<string>

Resources:
    + 3 to create

Updating (stack-outputs)

     Type                           Name               Status
 +   pulumi:pulumi:Stack            gcp-stack-outputs  created (6s)
 +   ├─ gcp:storage:Bucket          my-bucket          created (1s)
 +   └─ gcp:projects:IAMCustomRole  bucketViewerRole   created (2s)

Outputs:
    roleName: "bucketViewerRole"

Resources:
    + 3 created

Duration: 8s

You can see that the output you’ve created has been provided as a part of the update details. You will learn the different ways you can access this output in the next steps of the tutorial.

Access outputs via the CLI

Now that your resources are deployed, you can access its value either via the CLI or via your Pulumi program code. To access it via the CLI, you can use the pulumi stack output command. Running this command by itself will list the names and values of all of the exports in your program:

$ pulumi stack output

Current stack outputs (1):
    OUTPUT    VALUE
    roleName  bucketViewerRole

If you want to retrieve a specific output value, you will need to provide the name of your desired output as shown below:

$ pulumi stack output roleName

bucketViewerRole

This can be especially useful if you have any workflow scripts that depend on the outputs of your program. For example, if you wanted to view the details of your IAM Role using the Google Cloud CLI, you can do so by running the gcloud iam roles describe command and passing the output of roleName to the command, making sure to replace the value of <YOUR_PROJECT_NAME> with the name of your Google Cloud project:

$ gcloud iam roles describe --project=<YOUR_PROJECT_NAME> $(pulumi stack output roleName)

etag: BwYm3xAUufQ=
includedPermissions:
- storage.objects.get
- storage.objects.list
name: projects/pulumi-devrel/roles/bucketViewerRole
stage: GA
title: Bucket Viewer Role

You have seen how you can reference your output values from the CLI. Now let’s take a look at how you can do the same from within another Pulumi program stack.

Access outputs via stack reference

Stack references allow you to access the outputs of one stack from another stack. This enables developers to create resources even when there are inter-stack dependencies. For this section, you are going to create a new Pulumi program that will access stack output values from your existing program.

Reference resource group name

Start by making a new Pulumi project in a new directory. In this new program, you will need to add the code that will reference an output value from your first program. This can be done using Pulumi’s Stack Reference functionality. When defining a stack reference in code, you will need to pass in the fully qualified name of the stack as an argument. This name is comprised of the organization, project, and stack names in the format of <organization>/<project>/<stack>

For example, if the name of your organization is acmecorp, the name of your first program is infra, and the name of your stack is dev, then your fully qualified name will be acmecorp/infra/dev.

With that being said, a stack reference will look like the following in your code:

"use strict";
const pulumi = require("@pulumi/pulumi");

const stackRef = new pulumi.StackReference("acmecorp/infra/dev");

import * as pulumi from "@pulumi/pulumi";

const stackRef = new pulumi.StackReference("acmecorp/infra/dev");

import pulumi

stack_ref = pulumi.StackReference("acmecorp/infra/dev")

package main

import (
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
        stackRef, err := pulumi.NewStackReference(ctx, "acmecorp/infra/dev", nil)
        if err != nil {
            return err
        }

		return nil
	})
}

using Pulumi;

return await Pulumi.Deployment.RunAsync(() =>
{

    var stackRef = new StackReference("acmecorp/infra/dev");

});

name: my-second-app-dev
runtime: yaml
description: A program to create a Stack Reference

resources:
  stack-ref:
    type: pulumi:pulumi:StackReference
    properties:
      name: acmecorp/infra/dev

Make sure that the fully qualified name in the example above is populated with the values that are specific to your Pulumi organization, project, and stack.

You will now create an export in your second program that will output the value of the role name from your first program. This is to demonstrate how to retrieve output values from another stack for use in your program.

For the value of your export, you can retrieve it by taking your stack reference variable and using a Stack Reference function called getOutput() against it.

Update your code with the following:

"use strict";
const pulumi = require("@pulumi/pulumi");

// Retrieve the output values from the first stack
const stackRef = new pulumi.StackReference("acmecorp/infra/dev");

// Retrieve the role name from the output values
const roleName = stackRef.getOutput("roleName");

exports.roleName = roleName;

import * as pulumi from "@pulumi/pulumi";

// Retrieve the output values from the first stack
const stackRef = new pulumi.StackReference("acmecorp/infra/dev");

// Retrieve the role name from the output values
const roleName = stackRef.getOutput("roleName");

export const roleName = roleName;

import pulumi

# Retrieve the output values from the first stack
stack_ref = pulumi.StackReference("acmecorp/infra/dev")

# Retrieve the role name from the output values
role_name = stack_ref.get_output("roleName")

pulumi.export("roleName", role_name)

package main

import (
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
        // Retrieve the output values from the first stack
        stackRef, err := pulumi.NewStackReference(ctx, "acmecorp/infra/dev", nil)
        if err != nil {
            return err
        }

        // Retrieve the role name from the output values
        roleName := stackRef.GetOutput(pulumi.String("roleName"))

        ctx.Export("roleName", roleName)
		return nil
	})
}

using Pulumi;

return await Pulumi.Deployment.RunAsync(() =>
{
    // Retrieve the output values from the first stack
    var stackRef = new StackReference("acmecorp/infra/dev");

    // Retrieve the role name from the output values
    var roleName = stackRef.GetOutput("roleName");

    return new Dictionary<string, object?>
    {
        ["roleName"] = roleName
    };

});

name: my-second-app-dev
runtime: yaml
description: A program to create a Stack Reference

resources:
  # Retrieve the output values from the first stack
  stack-ref:
    type: pulumi:pulumi:StackReference
    properties:
      name: acmecorp/infra/dev

variables:
  # Retrieve the role name from the output values
  roleName: ${stack-ref.outputs["roleName"]}

outputs:
  roleName: ${roleName}

To verify that your stack reference is working, run pulumi up.

$ pulumi up -y

Previewing update (dev):

     Type                      Name                     Plan
 +   pulumi:pulumi:Stack  my-second-app-dev             create

Outputs:
    roleName: output<string>

Resources:
    + 4 to create

Do you want to perform this update? yes
Updating (dev):

     Type                      Name                     Status
 +   pulumi:pulumi:Stack  my-second-app-dev             created (2s)

Outputs:
    roleName: "bucketViewerRole"

Resources:
    + 4 created

Duration: 3s

You should see the name of your IAM role from your first program successfully outputted in the update details of your second program.

Use stack reference in resource definition

In this section, you will use everything you have learned in this tutorial to define a resource that uses a stack reference in the resource definition. In your second program, you will be defining a bucket object resource that will upload a file to the Storage Bucket that was created in your first program. Use the following steps as a guide for adding the Blob resource:

Navigate to the Google Cloud Registry documentation page
Search for the gcp.storage.BucketObject resource
Define the Bucket Object resource in your second program code
Export required property values in your first program code
Import required property values in your second program
Save and deploy your first program code
Then save and deploy your second program code

Once you have completed these steps, you can verify that the object was successfully created and uploaded to the conbuckettainer by navigating to Cloud Storage -> Buckets -> <YOUR_PROJECT_NAME> -> <YOUR_BUCKET_NAME> in the Google Cloud Portal.

View complete solution

You can view the code for the complete solution below.

First program code

"use strict";
const pulumi = require("@pulumi/pulumi");
const gcp = require("@pulumi/gcp");

const bucket = new gcp.storage.Bucket("bucket", {
    location: "US",
    forceDestroy: true,
});

const role = new gcp.projects.IAMCustomRole("role", {
    roleId: "bucketViewerRole",
    title: "Bucket Viewer Role",
    permissions: ["storage.objects.get", "storage.objects.list"],
    stage: "GA",
});

const bucketViewerRoleAssignment = new gcp.storage.BucketIAMMember("bucketViewerRoleAssignment", {
    bucket: bucket.name,
    role: role.name,
    member: "allAuthenticatedUsers",
});

exports.roleName = role.roleId;
exports.bucketName = bucket.name;

import * as pulumi from "@pulumi/pulumi";
import * as gcp from "@pulumi/gcp";

const bucket = new gcp.storage.Bucket("bucket", {
    location: "US",
    forceDestroy: true,
});

const role = new gcp.projects.IAMCustomRole("role", {
    roleId: "bucketViewerRole",
    title: "Bucket Viewer Role",
    permissions: ["storage.objects.get", "storage.objects.list"],
    stage: "GA",
});

const bucketViewerRoleAssignment = new gcp.storage.BucketIAMMember("bucketViewerRoleAssignment", {
    bucket: bucket.name,
    role: role.name,
    member: "allAuthenticatedUsers",
});

export const roleName1 = role.roleId;
export const bucketName1 = bucket.name;

import pulumi
from pulumi_gcp import storage, projects

role = projects.IAMCustomRole(
    "bucketViewerRole",
    role_id="bucketViewerRole",
    title="Bucket Viewer Role",
    permissions=[
        "storage.objects.get",
        "storage.objects.list"
    ],
    stage="GA"
)

bucket = storage.Bucket(
    "my-bucket",
    location="US",
    force_destroy=True
)

bucket_iam_member = storage.BucketIAMMember(
    "bucketViewerRoleAssignment",
    bucket=bucket.name,
    role=role.name,
    member="allAuthenticatedUsers"
)

pulumi.export("roleName", role.role_id)
pulumi.export("bucketName", bucket.name)

package main

import (
	"fmt"

	"github.com/pulumi/pulumi-gcp/sdk/v8/go/gcp/projects"
	"github.com/pulumi/pulumi-gcp/sdk/v8/go/gcp/storage"
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		bucket, err := storage.NewBucket(ctx, "bucket", &storage.BucketArgs{
			Location:     pulumi.String("US"),
			ForceDestroy: pulumi.Bool(true),
		})
		if err != nil {
			return err
		}

		role, err := projects.NewIAMCustomRole(ctx, "role", &projects.IAMCustomRoleArgs{
			RoleId: pulumi.String("bucketViewerRole"),
			Title:  pulumi.String("Bucket Viewer Role"),
			Permissions: pulumi.StringArray{
				pulumi.String("storage.objects.get"),
				pulumi.String("storage.objects.list"),
			},
			Stage: pulumi.String("GA"),
		})
		if err != nil {
			return err
		}

		_, err = storage.NewBucketIAMMember(ctx, "bucketViewerRoleAssignment", &storage.BucketIAMMemberArgs{
			Bucket: bucket.Name,
			Role:   role.Name,
			Member: pulumi.String("allAuthenticatedUsers"),
		})
		if err != nil {
			return err
		}

		ctx.Export("roleName", role.RoleId)
		ctx.Export("bucketName", bucket.Name)
		return nil
	})
}

using System.Collections.Generic;
using System.Linq;
using Pulumi;
using Gcp = Pulumi.Gcp;

return await Deployment.RunAsync(() =>
{
    var bucket = new Gcp.Storage.Bucket("bucket", new()
    {
        Location = "US",
        ForceDestroy = true,
    });

    var role = new Gcp.Projects.IAMCustomRole("role", new()
    {
        RoleId = "bucketViewerRole",
        Title = "Bucket Viewer Role",
        Permissions = new[]
        {
            "storage.objects.get",
            "storage.objects.list",
        },
        Stage = "GA",
    });

    var bucketViewerRoleAssignment = new Gcp.Storage.BucketIAMMember("bucketViewerRoleAssignment", new()
    {
        Bucket = bucket.Name,
        Role = role.Name,
        Member = "allAuthenticatedUsers",
    });

    return new Dictionary<string, object?>
    {
        ["roleName"] = role.RoleId,
        ["bucketName"] = bucket.Name,
    };
});

name: gcp-storage-bucket-object-yaml
description: An example that deploys a storage bucket and uploads a file on Google Cloud.
runtime: yaml

resources:
  role:
    type: gcp:projects:IAMCustomRole
    properties:
      roleId: bucketViewerRole
      title: Bucket Viewer Role
      permissions:
        - storage.objects.get
        - storage.objects.list
      stage: GA

  bucket:
    type: gcp:storage:Bucket
    properties:
      location: US
      forceDestroy: true

  bucketViewerRoleAssignment:
    type: gcp:storage:BucketIAMMember
    properties:
      bucket: ${bucket.name}
      role: ${role.name}
      member: allAuthenticatedUsers

outputs:
  roleName: ${role.name}
  bucketName: ${bucket.name}

Second program code

"use strict";
const pulumi = require("@pulumi/pulumi");

const stackRef = new pulumi.StackReference("acmecorp/infra/dev");

const roleName = stackRef.getOutput("roleName");
const bucketName = stackRef.getOutput("bucketName");

const bucketObject = new gcp.storage.BucketObject("bucketObject", {
    bucket: bucketName,
    content: pulumi.interpolate`My bucket role name is: ${roleName}`,
    contentType: "text/plain",
});

import * as pulumi from "@pulumi/pulumi";

const stackRef = new pulumi.StackReference("acmecorp/infra/dev");

const roleName2 = stackRef.getOutput("roleName");
const bucketName2 = stackRef.getOutput("bucketName");

const bucketObject = new gcp.storage.BucketObject("bucketObject", {
    bucket: bucketName,
    content: pulumi.interpolate`My bucket role name is: ${roleName}`,
    contentType: "text/plain",
});

import pulumi

stack_ref = pulumi.StackReference("acmecorp/infra/dev")

role_name = stack_ref.get_output("roleName")
bucket_name = stack_ref.get_output("bucketName")

bucket_object = storage.BucketObject(
    "my-object",
    bucket=bucket_name,
    source=pulumi.StringAsset(file_content),
    content_type="text/plain"
)

package main

import (
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
        stackRef, err := pulumi.NewStackReference(ctx, "acmecorp/infra/dev", nil)
        if err != nil {
            return err
        }

        roleName := stackRef.GetOutput(pulumi.String("roleName"))
        bucketName := stackRef.GetOutput(pulumi.String("bucketName"))


		_, err = storage.NewBucketObject(ctx, "bucketObject", &storage.BucketObjectArgs{
			Bucket: bucketName,
			Content: roleName.ApplyT(func(roleName string) (string, error) {
				return fmt.Sprintf("My bucket role name is: %v", roleName), nil
			}).(pulumi.StringOutput),
			ContentType: pulumi.String("text/plain"),
		})
		if err != nil {
			return err
		}

		return nil
	})
}

using Pulumi;

return await Pulumi.Deployment.RunAsync(() =>
{

    var stackRef = new StackReference("acmecorp/infra/dev");

    var roleName = stackRef.GetOutput("roleName");
    var bucketName = stackRef.GetOutput("bucketName");

    var bucketObject = new Gcp.Storage.BucketObject("bucketObject", new()
    {
        Bucket = bucketName,
        Content = roleName.Apply(roleName => $"My bucket role name is: {roleName}"),
        ContentType = "text/plain",
    });

});

name: infra
runtime: yaml
description: A program to create a Stack Reference

resources:
  stack-ref:
    type: pulumi:pulumi:StackReference
    properties:
      name: acmecorp/infra/dev

  bucketObject:
    type: gcp:storage:BucketObject
    properties:
      bucket: ${bucketName}
      content: "My bucket role name is: ${roleName}"
      contentType: text/plain

variables:
  roleName: ${stack-ref.outputs["roleName"]}
  bucketName: ${stack-ref.outputs["bucketName"]}

Clean up

Before moving on, tear down the resources that are part of your stack to avoid incurring any charges.

Run pulumi destroy to tear down all resources. You'll be prompted to make sure you really want to delete these resources. A destroy operation may take some time, since Pulumi waits for the resources to finish shutting down before it considers the destroy operation to be complete.
To delete the stack itself, run pulumi stack rm. Note that this command deletes all deployment history from the Pulumi Service.

Next steps

In this tutorial, you created a Google Cloud Storage Bucket and custom IAM role. You also referenced the documentation to create a storage object that would upload a file to the bucket. You exported resource properties into stack outputs, and referenced those outputs across stacks using stack references.

To learn more about creating and managing resources in Pulumi, take a look at the following resources:

Learn more about creating resources in the Creating Resources on Google Cloud tutorial.
Learn more about stack outputs and references in the Pulumi documentation.
Learn more about Pulumi inputs and outputs in the Pulumi documentation.

Platform Engineering Workshop Series - Register Now
