Getting Started with Amazon EKS Auto Mode in Pulumi

import * as pulumi from "@pulumi/pulumi";
import * as awsx from "@pulumi/awsx";
import * as eks from "@pulumi/eks";
import * as k8s from "@pulumi/kubernetes";
import { SubnetType } from "@pulumi/awsx/ec2";

const config = new pulumi.Config();
const clusterName = config.require("clusterName");

const eksVpc = new awsx.ec2.Vpc("eks-auto-mode", {
    enableDnsHostnames: true,
    cidrBlock: "10.0.0.0/16",
    subnetSpecs: [
        // Necessary tags for EKS Auto Mode to identify the subnets for the load balancers.
        // See: https://kubernetes-sigs.github.io/aws-load-balancer-controller/v2.1/deploy/subnet_discovery/
        {type: SubnetType.Public, tags: {[`kubernetes.io/cluster/${clusterName}`]: "shared", "kubernetes.io/role/elb": "1"}},
        {type: SubnetType.Private, tags: {[`kubernetes.io/cluster/${clusterName}`]: "shared", "kubernetes.io/role/internal-elb": "1"}},
    ],
    subnetStrategy: "Auto"
});

const cluster = new eks.Cluster("eks-auto-mode", {
    name: clusterName,
    // EKS Auto Mode requires Access Entries, use either the `Api` or `ApiAndConfigMap` authentication mode.
    authenticationMode: eks.AuthenticationMode.Api,
    vpcId: eksVpc.vpcId,
    publicSubnetIds: eksVpc.publicSubnetIds,
    privateSubnetIds: eksVpc.privateSubnetIds,
    // Enables compute, storage and load balancing for the cluster.
    autoMode: {
        enabled: true,
    }
});

import pulumi
import pulumi_awsx as awsx
import pulumi_eks as eks
import pulumi_kubernetes as kubernetes

eks_vpc = awsx.ec2.Vpc("eksVpc",
    enable_dns_hostnames=True,
    cidr_block="10.0.0.0/16",
    # Necessary tags for EKS Auto Mode to identify the subnets for the load balancers.
    # See: https://kubernetes-sigs.github.io/aws-load-balancer-controller/v2.1/deploy/subnet_discovery/
    subnet_specs=[
        {
            "type": awsx.ec2.SubnetType.PUBLIC,
            "tags": {
                "kubernetes_io_cluster_eks_auto_mode_demo": "shared",
                "kubernetes_io_role_elb": "1",
            },
        },
        {
            "type": awsx.ec2.SubnetType.PRIVATE,
            "tags": {
                "kubernetes_io_cluster_eks_auto_mode_demo": "shared",
                "kubernetes_io_role_internal_elb": "1",
            },
        },
    ],
    subnet_strategy=awsx.ec2.SubnetAllocationStrategy.AUTO)
cluster = eks.Cluster("cluster",
    name="eks-auto-mode-demo",
    # EKS Auto Mode requires Access Entries, use either the `Api` or `ApiAndConfigMap` authentication mode.
    authentication_mode=eks.AuthenticationMode.API,
    vpc_id=eks_vpc.vpc_id,
    public_subnet_ids=eks_vpc.public_subnet_ids,
    private_subnet_ids=eks_vpc.private_subnet_ids,
    # Enables compute, storage and load balancing for the cluster.
    auto_mode={
        "enabled": True,
    })

package main

import (
	"github.com/pulumi/pulumi-awsx/sdk/v2/go/awsx/ec2"
	"github.com/pulumi/pulumi-eks/sdk/v3/go/eks"
	"github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes"
	appsv1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/apps/v1"
	corev1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/core/v1"
	metav1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/meta/v1"
	networkingv1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/networking/v1"
	storagev1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/storage/v1"
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		eksVpc, err := ec2.NewVpc(ctx, "eksVpc", &ec2.VpcArgs{
			EnableDnsHostnames: pulumi.Bool(true),
			CidrBlock:          "10.0.0.0/16",
            // Necessary tags for EKS Auto Mode to identify the subnets for the load balancers.
            // See: https://kubernetes-sigs.github.io/aws-load-balancer-controller/v2.1/deploy/subnet_discovery/
			SubnetSpecs: []ec2.SubnetSpecArgs{
				{
					Type: ec2.SubnetTypePublic,
					Tags: {
						"kubernetes.io/cluster/eks-auto-mode-demo": pulumi.String("shared"),
						"kubernetes.io/role/elb":                   pulumi.String("1"),
					},
				},
				{
					Type: ec2.SubnetTypePrivate,
					Tags: {
						"kubernetes.io/cluster/eks-auto-mode-demo": pulumi.String("shared"),
						"kubernetes.io/role/internal-elb":          pulumi.String("1"),
					},
				},
			},
			SubnetStrategy: ec2.SubnetAllocationStrategyAuto,
		})
		if err != nil {
			return err
		}
		cluster, err := eks.NewCluster(ctx, "cluster", &eks.ClusterArgs{
			Name:                      pulumi.String("eks-auto-mode-demo"),
            // EKS Auto Mode requires Access Entries, use either the `Api` or `ApiAndConfigMap` authentication mode.
			AuthenticationMode:        eks.AuthenticationModeApi,
			VpcId:                     eksVpc.VpcId,
			PublicSubnetIds:           eksVpc.PublicSubnetIds,
			PrivateSubnetIds:          eksVpc.PrivateSubnetIds,
            // Enables compute, storage and load balancing for the cluster.
			AutoMode: &eks.AutoModeOptionsArgs{
				Enabled: true,
			},
		})
		if err != nil {
			return err
		}
        return nil
	})
}

using System.Collections.Generic;
using System.Linq;
using Pulumi;
using Awsx = Pulumi.Awsx;
using Eks = Pulumi.Eks;
using Kubernetes = Pulumi.Kubernetes;

return await Deployment.RunAsync(() =>
{
    var eksVpc = new Awsx.Ec2.Vpc("eksVpc", new()
    {
        EnableDnsHostnames = true,
        CidrBlock = "10.0.0.0/16",
        // Necessary tags for EKS Auto Mode to identify the subnets for the load balancers.
        // See: https://kubernetes-sigs.github.io/aws-load-balancer-controller/v2.1/deploy/subnet_discovery/
        SubnetSpecs = new()
        {
            new Awsx.Ec2.Inputs.SubnetSpecArgs
            {
                Type = Awsx.Ec2.SubnetType.Public,
                Tags =
                {
                    { "kubernetes.io/cluster/eks-auto-mode-demo", "shared" },
                    { "kubernetes.io/role/elb", "1" },
                },
            },
            new Awsx.Ec2.Inputs.SubnetSpecArgs
            {
                Type = Awsx.Ec2.SubnetType.Private,
                Tags =
                {
                    { "kubernetes.io/cluster/eks-auto-mode-demo", "shared" },
                    { "kubernetes.io/role/internal-elb", "1" },
                },
            },
        },
        SubnetStrategy = Awsx.Ec2.SubnetAllocationStrategy.Auto,
    });

    var cluster = new Eks.Cluster("cluster", new()
    {
        Name = "eks-auto-mode-demo",
        // EKS Auto Mode requires Access Entries, use either the `Api` or `ApiAndConfigMap` authentication mode.
        AuthenticationMode = Eks.AuthenticationMode.Api,
        VpcId = eksVpc.VpcId,
        PublicSubnetIds = eksVpc.PublicSubnetIds,
        PrivateSubnetIds = eksVpc.PrivateSubnetIds,
        // Enables compute, storage and load balancing for the cluster.
        AutoMode = new Eks.Inputs.AutoModeOptionsArgs
        {
            Enabled = true,
        },
    });
});

import com.pulumi.Context;
import com.pulumi.Pulumi;
import com.pulumi.core.Output;
import com.pulumi.awsx.ec2.Vpc;
import com.pulumi.awsx.ec2.VpcArgs;
import com.pulumi.awsx.ec2.inputs.SubnetSpecArgs;
import com.pulumi.eks.Cluster;
import com.pulumi.eks.ClusterArgs;
import com.pulumi.eks.inputs.AutoModeOptionsArgs;
import com.pulumi.resources.CustomResourceOptions;
import java.util.List;
import java.util.ArrayList;
import java.util.Map;

public class App {
    public static void main(String[] args) {
        Pulumi.run(App::stack);
    }

    public static void stack(Context ctx) {
        var eksVpc = new Vpc("eksVpc", VpcArgs.builder()
            .enableDnsHostnames(true)
            .cidrBlock("10.0.0.0/16")
            // Necessary tags for EKS Auto Mode to identify the subnets for the load balancers.
            // See: https://kubernetes-sigs.github.io/aws-load-balancer-controller/v2.1/deploy/subnet_discovery/
            .subnetSpecs(
                SubnetSpecArgs.builder()
                    .type("Public")
                    .tags(Map.ofEntries(
                        Map.entry("kubernetes.io/cluster/eks-auto-mode-demo", "shared"),
                        Map.entry("kubernetes.io/role/elb", "1")
                    ))
                    .build(),
                SubnetSpecArgs.builder()
                    .type("Private")
                    .tags(Map.ofEntries(
                        Map.entry("kubernetes.io/cluster/eks-auto-mode-demo", "shared"),
                        Map.entry("kubernetes.io/role/internal-elb", "1")
                    ))
                    .build())
            .subnetStrategy("Auto")
            .build());

        var cluster = new Cluster("cluster", ClusterArgs.builder()
            .name("eks-auto-mode-demo")
            // EKS Auto Mode requires Access Entries, use either the `Api` or `ApiAndConfigMap` authentication mode.
            .authenticationMode("API")
            .vpcId(eksVpc.vpcId())
            .publicSubnetIds(eksVpc.publicSubnetIds())
            .privateSubnetIds(eksVpc.privateSubnetIds())
            // Enables compute, storage and load balancing for the cluster.
            .autoMode(AutoModeOptionsArgs.builder()
                .enabled(true)
                .build())
            .build());
    }
}

name: eks-auto-mode-demo
description: A demo of EKS Auto Mode
runtime: yaml
resources:
  eksVpc:
    type: awsx:ec2:Vpc
    properties:
      enableDnsHostnames: true
      cidrBlock: "10.0.0.0/16"
      # Necessary tags for EKS Auto Mode to identify the subnets for the load balancers.
      # See: https://kubernetes-sigs.github.io/aws-load-balancer-controller/v2.1/deploy/subnet_discovery/
      subnetSpecs:
        - type: "Public"
          tags:
            kubernetes.io/cluster/eks-auto-mode-demo: shared
            kubernetes.io/role/elb: "1"
        - type: "Private"
          tags:
            kubernetes.io/cluster/eks-auto-mode-demo: shared
            kubernetes.io/role/internal-elb: "1"
      subnetStrategy: "Auto"
  cluster:
    type: eks:Cluster
    properties:
      name: eks-auto-mode-demo
      # EKS Auto Mode requires Access Entries, use either the `Api` or `ApiAndConfigMap` authentication mode.
      authenticationMode: API
      vpcId: ${eksVpc.vpcId}
      publicSubnetIds: ${eksVpc.publicSubnetIds}
      privateSubnetIds: ${eksVpc.privateSubnetIds}
      # Enables compute, storage and load balancing for the cluster.
      autoMode:
        enabled: true

//...
const appName = "nginx";
const ns = new k8s.core.v1.Namespace(appName, {
    metadata: { name: appName },
}, { provider: cluster.provider });

const configMap = new k8s.core.v1.ConfigMap(appName, {
    metadata: {
        namespace: ns.metadata.name,
    },
    data: {
        "index.html": "<html><body><h1>Hello, Pulumi!</h1></body></html>",
    },
}, { provider: cluster.provider });

const deployment = new k8s.apps.v1.Deployment(appName, {
    metadata: {
        namespace: ns.metadata.name
    },
    spec: {
        selector: { matchLabels: { app: appName } },
        replicas: 3,
        template: {
            metadata: { labels: { app: appName } },
            spec: {
                containers: [{
                    name: appName,
                    image: appName,
                    ports: [{ containerPort: 80 }],
                    volumeMounts: [{ name: "nginx-index", mountPath: "/usr/share/nginx/html" }],
                }],
                volumes: [{
                    name: "nginx-index",
                    configMap: { name: configMap.metadata.name },
                }],
            },
        },
    },
}, { provider: cluster.provider });

const service = new k8s.core.v1.Service(appName, {
    metadata: {
        name: appName,
        namespace: ns.metadata.name
    },
    spec: {
        selector: { app: appName },
        ports: [{ port: 80, targetPort: 80 }],
    },
}, { provider: cluster.provider, dependsOn: [deployment] });

const ingressClass = new k8s.networking.v1.IngressClass("alb", {
    metadata: {
        namespace: ns.metadata.name,
        labels: {
            "app.kubernetes.io/name": "LoadBalancerController",
        },
        name: "alb",
    },
    spec: {
        controller: "eks.amazonaws.com/alb",
    }
}, { provider: cluster.provider });

const ingress = new k8s.networking.v1.Ingress(appName, {
    metadata: {
        namespace: ns.metadata.name,
        // Annotations for EKS Auto Mode to identify the Ingress as internet-facing and target-type as IP.
        annotations: {
            "alb.ingress.kubernetes.io/scheme": "internet-facing",
            "alb.ingress.kubernetes.io/target-type": "ip",
        }
    },
    spec: {
        ingressClassName: ingressClass.metadata.name,
        rules: [{
            http: {
                paths: [{
                    path: "/",
                    pathType: "Prefix",
                    backend: {
                        service: {
                            name: service.metadata.name,
                            port: {
                                number: 80,
                            },
                        },
                    },
                }],
            },
        }],
    }
}, { provider: cluster.provider });

export const url = ingress.status.apply(status => status?.loadBalancer?.ingress?.[0]?.hostname);

# ...
k8s_provider = kubernetes.Provider("k8sProvider", kubeconfig=cluster.kubeconfig)
ns = kubernetes.core.v1.Namespace("ns", metadata={
    "name": "nginx",
},
opts = pulumi.ResourceOptions(provider=k8s_provider))
index_content = kubernetes.core.v1.ConfigMap("index-content",
    metadata={
        "namespace": ns.metadata.name,
    },
    data={
        "index.html": "<html><body><h1>Hello, Pulumi!</h1></body></html>",
    },
    opts = pulumi.ResourceOptions(provider=k8s_provider))
deployment = kubernetes.apps.v1.Deployment("deployment",
    metadata={
        "namespace": ns.metadata.name,
    },
    spec={
        "selector": {
            "match_labels": {
                "app": "nginx",
            },
        },
        "replicas": 3,
        "template": {
            "metadata": {
                "labels": {
                    "app": "nginx",
                },
            },
            "spec": {
                "containers": [{
                    "name": "nginx",
                    "image": "nginx",
                    "ports": [{
                        "container_port": 80,
                    }],
                    "volume_mounts": [{
                        "name": "nginx-index",
                        "mount_path": "/usr/share/nginx/html",
                    }],
                }],
                "volumes": [{
                    "name": "nginx-index",
                    "config_map": {
                        "name": index_content.metadata.name,
                    },
                }],
            },
        },
    },
    opts = pulumi.ResourceOptions(provider=k8s_provider))
service = kubernetes.core.v1.Service("service",
    metadata={
        "name": "nginx",
        "namespace": ns.metadata.name,
    },
    spec={
        "selector": {
            "app": "nginx",
        },
        "ports": [{
            "port": 80,
            "target_port": 80,
        }],
    },
    opts = pulumi.ResourceOptions(provider=k8s_provider,
        depends_on=[deployment]))
ingress_class = kubernetes.networking.v1.IngressClass("ingressClass",
    metadata={
        "namespace": ns.metadata.name,
        "labels": {
            "app_kubernetes_io_name": "LoadBalancerController",
        },
        "name": "alb",
    },
    spec={
        "controller": "eks.amazonaws.com/alb",
    },
    opts = pulumi.ResourceOptions(provider=k8s_provider))
ingress = kubernetes.networking.v1.Ingress("ingress",
    metadata={
        "namespace": ns.metadata.name,
        "annotations": {
            "alb_ingress_kubernetes_io_scheme": "internet-facing",
            "alb_ingress_kubernetes_io_target_type": "ip",
        },
    },
    spec={
        "ingress_class_name": ingress_class.metadata.name,
        "rules": [{
            "http": {
                "paths": [{
                    "path": "/",
                    "path_type": "Prefix",
                    "backend": {
                        "service": {
                            "name": service.metadata.name,
                            "port": {
                                "number": 80,
                            },
                        },
                    },
                }],
            },
        }],
    },
    opts = pulumi.ResourceOptions(provider=k8s_provider))

pulumi.export("url", ingress.status.load_balancer.ingress[0].hostname)

package main

import (
	"github.com/pulumi/pulumi-awsx/sdk/v2/go/awsx/ec2"
	"github.com/pulumi/pulumi-eks/sdk/v3/go/eks"
	"github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes"
	appsv1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/apps/v1"
	corev1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/core/v1"
	metav1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/meta/v1"
	networkingv1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/networking/v1"
	storagev1 "github.com/pulumi/pulumi-kubernetes/sdk/v4/go/kubernetes/storage/v1"
	"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		// ...
		k8sProvider, err := kubernetes.NewProvider(ctx, "k8sProvider", &kubernetes.ProviderArgs{
			Kubeconfig: cluster.Kubeconfig,
		})
		if err != nil {
			return err
		}
		ns, err := corev1.NewNamespace(ctx, "ns", &corev1.NamespaceArgs{
			Metadata: &metav1.ObjectMetaArgs{
				Name: pulumi.String("nginx"),
			},
		}, pulumi.Provider(k8sProvider))
		if err != nil {
			return err
		}
		indexContent, err := corev1.NewConfigMap(ctx, "index-content", &corev1.ConfigMapArgs{
			Metadata: &metav1.ObjectMetaArgs{
				Namespace: ns.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
					return &metadata.Name, nil
				}).(pulumi.StringPtrOutput),
			},
			Data: pulumi.StringMap{
				"index.html": pulumi.String("<html><body><h1>Hello, Pulumi!</h1></body></html>"),
			},
		}, pulumi.Provider(k8sProvider))
		if err != nil {
			return err
		}
		deployment, err := appsv1.NewDeployment(ctx, "deployment", &appsv1.DeploymentArgs{
			Metadata: &metav1.ObjectMetaArgs{
				Namespace: ns.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
					return &metadata.Name, nil
				}).(pulumi.StringPtrOutput),
			},
			Spec: &appsv1.DeploymentSpecArgs{
				Selector: &metav1.LabelSelectorArgs{
					MatchLabels: pulumi.StringMap{
						"app": pulumi.String("nginx"),
					},
				},
				Replicas: pulumi.Int(3),
				Template: &corev1.PodTemplateSpecArgs{
					Metadata: &metav1.ObjectMetaArgs{
						Labels: pulumi.StringMap{
							"app": pulumi.String("nginx"),
						},
					},
					Spec: &corev1.PodSpecArgs{
						Containers: corev1.ContainerArray{
							&corev1.ContainerArgs{
								Name:  pulumi.String("nginx"),
								Image: pulumi.String("nginx"),
								Ports: corev1.ContainerPortArray{
									&corev1.ContainerPortArgs{
										ContainerPort: pulumi.Int(80),
									},
								},
								VolumeMounts: corev1.VolumeMountArray{
									&corev1.VolumeMountArgs{
										Name:      pulumi.String("nginx-index"),
										MountPath: pulumi.String("/usr/share/nginx/html"),
									},
								},
							},
						},
						Volumes: corev1.VolumeArray{
							&corev1.VolumeArgs{
								Name: pulumi.String("nginx-index"),
								ConfigMap: &corev1.ConfigMapVolumeSourceArgs{
									Name: indexContent.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
										return &metadata.Name, nil
									}).(pulumi.StringPtrOutput),
								},
							},
						},
					},
				},
			},
		}, pulumi.Provider(k8sProvider))
		if err != nil {
			return err
		}
		service, err := corev1.NewService(ctx, "service", &corev1.ServiceArgs{
			Metadata: &metav1.ObjectMetaArgs{
				Name: pulumi.String("nginx"),
				Namespace: ns.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
					return &metadata.Name, nil
				}).(pulumi.StringPtrOutput),
			},
			Spec: &corev1.ServiceSpecArgs{
				Selector: pulumi.StringMap{
					"app": pulumi.String("nginx"),
				},
				Ports: corev1.ServicePortArray{
					&corev1.ServicePortArgs{
						Port:       pulumi.Int(80),
						TargetPort: pulumi.Any(80),
					},
				},
			},
		}, pulumi.Provider(k8sProvider), pulumi.DependsOn([]pulumi.Resource{
			deployment,
		}))
		if err != nil {
			return err
		}
		ingressClass, err := networkingv1.NewIngressClass(ctx, "ingressClass", &networkingv1.IngressClassArgs{
			Metadata: &metav1.ObjectMetaArgs{
				Namespace: ns.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
					return &metadata.Name, nil
				}).(pulumi.StringPtrOutput),
				Labels: pulumi.StringMap{
					"app.kubernetes.io/name": pulumi.String("LoadBalancerController"),
				},
				Name: pulumi.String("alb"),
			},
			Spec: &networkingv1.IngressClassSpecArgs{
				Controller: pulumi.String("eks.amazonaws.com/alb"),
			},
		}, pulumi.Provider(k8sProvider))
		if err != nil {
			return err
		}
		ingress, err := networkingv1.NewIngress(ctx, "ingress", &networkingv1.IngressArgs{
			Metadata: &metav1.ObjectMetaArgs{
				Namespace: ns.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
					return &metadata.Name, nil
				}).(pulumi.StringPtrOutput),
				Annotations: pulumi.StringMap{
					"alb.ingress.kubernetes.io/scheme":      pulumi.String("internet-facing"),
					"alb.ingress.kubernetes.io/target-type": pulumi.String("ip"),
				},
			},
			Spec: &networkingv1.IngressSpecArgs{
				IngressClassName: ingressClass.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
					return &metadata.Name, nil
				}).(pulumi.StringPtrOutput),
				Rules: networkingv1.IngressRuleArray{
					&networkingv1.IngressRuleArgs{
						Http: &networkingv1.HTTPIngressRuleValueArgs{
							Paths: networkingv1.HTTPIngressPathArray{
								&networkingv1.HTTPIngressPathArgs{
									Path:     pulumi.String("/"),
									PathType: pulumi.String("Prefix"),
									Backend: &networkingv1.IngressBackendArgs{
										Service: &networkingv1.IngressServiceBackendArgs{
											Name: service.Metadata.ApplyT(func(metadata metav1.ObjectMeta) (*string, error) {
												return &metadata.Name, nil
											}).(pulumi.StringPtrOutput),
											Port: &networkingv1.ServiceBackendPortArgs{
												Number: pulumi.Int(80),
											},
										},
									},
								},
							},
						},
					},
				},
			},
		}, pulumi.Provider(k8sProvider))
		if err != nil {
			return err
		}

		ctx.Export("url", ingress.Status.ApplyT(func(status networkingv1.IngressStatus) (*string, error) {
			return &status.LoadBalancer.Ingress[0].Hostname, nil
		}).(pulumi.StringPtrOutput))
		return nil
	})
}

using System.Collections.Generic;
using System.Linq;
using Pulumi;
using Awsx = Pulumi.Awsx;
using Eks = Pulumi.Eks;
using Kubernetes = Pulumi.Kubernetes;

return await Deployment.RunAsync(() =>
{
    // ...
    var k8sProvider = new Kubernetes.Provider.Provider("k8sProvider", new()
    {
        KubeConfig = cluster.Kubeconfig,
    });

    var ns = new Kubernetes.Core.V1.Namespace("ns", new()
    {
        Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
        {
            Name = "nginx",
        },
    }, new CustomResourceOptions
    {
        Provider = k8sProvider,
    });

    var indexContent = new Kubernetes.Core.V1.ConfigMap("index-content", new()
    {
        Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
        {
            Namespace = ns.Metadata.Apply(metadata => metadata.Name),
        },
        Data =
        {
            { "index.html", "<html><body><h1>Hello, Pulumi!</h1></body></html>" },
        },
    }, new CustomResourceOptions
    {
        Provider = k8sProvider,
    });

    var deployment = new Kubernetes.Apps.V1.Deployment("deployment", new()
    {
        Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
        {
            Namespace = ns.Metadata.Apply(metadata => metadata.Name),
        },
        Spec = new Kubernetes.Types.Inputs.Apps.V1.DeploymentSpecArgs
        {
            Selector = new Kubernetes.Types.Inputs.Meta.V1.LabelSelectorArgs
            {
                MatchLabels =
                {
                    { "app", "nginx" },
                },
            },
            Replicas = 3,
            Template = new Kubernetes.Types.Inputs.Core.V1.PodTemplateSpecArgs
            {
                Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
                {
                    Labels =
                    {
                        { "app", "nginx" },
                    },
                },
                Spec = new Kubernetes.Types.Inputs.Core.V1.PodSpecArgs
                {
                    Containers = new[]
                    {
                        new Kubernetes.Types.Inputs.Core.V1.ContainerArgs
                        {
                            Name = "nginx",
                            Image = "nginx",
                            Ports = new[]
                            {
                                new Kubernetes.Types.Inputs.Core.V1.ContainerPortArgs
                                {
                                    ContainerPortValue = 80,
                                },
                            },
                            VolumeMounts = new[]
                            {
                                new Kubernetes.Types.Inputs.Core.V1.VolumeMountArgs
                                {
                                    Name = "nginx-index",
                                    MountPath = "/usr/share/nginx/html",
                                },
                            },
                        },
                    },
                    Volumes = new[]
                    {
                        new Kubernetes.Types.Inputs.Core.V1.VolumeArgs
                        {
                            Name = "nginx-index",
                            ConfigMap = new Kubernetes.Types.Inputs.Core.V1.ConfigMapVolumeSourceArgs
                            {
                                Name = indexContent.Metadata.Apply(metadata => metadata.Name),
                            },
                        },
                    },
                },
            },
        },
    }, new CustomResourceOptions
    {
        Provider = k8sProvider,
    });

    var service = new Kubernetes.Core.V1.Service("service", new()
    {
        Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
        {
            Name = "nginx",
            Namespace = ns.Metadata.Apply(metadata => metadata.Name),
        },
        Spec = new Kubernetes.Types.Inputs.Core.V1.ServiceSpecArgs
        {
            Selector =
            {
                { "app", "nginx" },
            },
            Ports = new[]
            {
                new Kubernetes.Types.Inputs.Core.V1.ServicePortArgs
                {
                    Port = 80,
                    TargetPort = 80,
                },
            },
        },
    }, new CustomResourceOptions
    {
        Provider = k8sProvider,
        DependsOn =
        {
            deployment,
        },
    });

    var ingressClass = new Kubernetes.Networking.V1.IngressClass("ingressClass", new()
    {
        Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
        {
            Namespace = ns.Metadata.Apply(metadata => metadata.Name),
            Labels =
            {
                { "app.kubernetes.io/name", "LoadBalancerController" },
            },
            Name = "alb",
        },
        Spec = new Kubernetes.Types.Inputs.Networking.V1.IngressClassSpecArgs
        {
            Controller = "eks.amazonaws.com/alb",
        },
    }, new CustomResourceOptions
    {
        Provider = k8sProvider,
    });

    var ingress = new Kubernetes.Networking.V1.Ingress("ingress", new()
    {
        Metadata = new Kubernetes.Types.Inputs.Meta.V1.ObjectMetaArgs
        {
            Namespace = ns.Metadata.Apply(metadata => metadata.Name),
            Annotations =
            {
                { "alb.ingress.kubernetes.io/scheme", "internet-facing" },
                { "alb.ingress.kubernetes.io/target-type", "ip" },
            },
        },
        Spec = new Kubernetes.Types.Inputs.Networking.V1.IngressSpecArgs
        {
            IngressClassName = ingressClass.Metadata.Apply(metadata => metadata.Name),
            Rules = new[]
            {
                new Kubernetes.Types.Inputs.Networking.V1.IngressRuleArgs
                {
                    Http = new Kubernetes.Types.Inputs.Networking.V1.HTTPIngressRuleValueArgs
                    {
                        Paths = new[]
                        {
                            new Kubernetes.Types.Inputs.Networking.V1.HTTPIngressPathArgs
                            {
                                Path = "/",
                                PathType = "Prefix",
                                Backend = new Kubernetes.Types.Inputs.Networking.V1.IngressBackendArgs
                                {
                                    Service = new Kubernetes.Types.Inputs.Networking.V1.IngressServiceBackendArgs
                                    {
                                        Name = service.Metadata.Apply(metadata => metadata.Name),
                                        Port = new Kubernetes.Types.Inputs.Networking.V1.ServiceBackendPortArgs
                                        {
                                            Number = 80,
                                        },
                                    },
                                },
                            },
                        },
                    },
                },
            },
        },
    }, new CustomResourceOptions
    {
        Provider = k8sProvider,
    });

    return new Dictionary<string, object?>
    {
        ["url"] = ingress.Status.Apply(status => status?.LoadBalancer?.Ingress[0]?.Hostname),
    };
});

package generated_program;

import com.pulumi.Context;
import com.pulumi.Pulumi;
import com.pulumi.core.Output;
import com.pulumi.awsx.ec2.Vpc;
import com.pulumi.awsx.ec2.VpcArgs;
import com.pulumi.awsx.ec2.inputs.SubnetSpecArgs;
import com.pulumi.eks.Cluster;
import com.pulumi.eks.ClusterArgs;
import com.pulumi.eks.inputs.AutoModeOptionsArgs;
import com.pulumi.kubernetes.Provider;
import com.pulumi.kubernetes.ProviderArgs;
import com.pulumi.kubernetes.core_v1.Namespace;
import com.pulumi.kubernetes.core_v1.NamespaceArgs;
import com.pulumi.kubernetes.meta_v1.inputs.ObjectMetaArgs;
import com.pulumi.kubernetes.core_v1.ConfigMap;
import com.pulumi.kubernetes.core_v1.ConfigMapArgs;
import com.pulumi.kubernetes.apps_v1.Deployment;
import com.pulumi.kubernetes.apps_v1.DeploymentArgs;
import com.pulumi.kubernetes.apps_v1.inputs.DeploymentSpecArgs;
import com.pulumi.kubernetes.meta_v1.inputs.LabelSelectorArgs;
import com.pulumi.kubernetes.core_v1.inputs.PodTemplateSpecArgs;
import com.pulumi.kubernetes.core_v1.inputs.PodSpecArgs;
import com.pulumi.kubernetes.core_v1.Service;
import com.pulumi.kubernetes.core_v1.ServiceArgs;
import com.pulumi.kubernetes.core_v1.inputs.ServiceSpecArgs;
import com.pulumi.kubernetes.networking.k8s.io_v1.IngressClass;
import com.pulumi.kubernetes.networking.k8s.io_v1.IngressClassArgs;
import com.pulumi.kubernetes.networking.k8s.io_v1.inputs.IngressClassSpecArgs;
import com.pulumi.kubernetes.networking.k8s.io_v1.Ingress;
import com.pulumi.kubernetes.networking.k8s.io_v1.IngressArgs;
import com.pulumi.kubernetes.networking.k8s.io_v1.inputs.IngressSpecArgs;
import com.pulumi.kubernetes.storage.k8s.io_v1.StorageClass;
import com.pulumi.kubernetes.storage.k8s.io_v1.StorageClassArgs;
import com.pulumi.kubernetes.core_v1.PersistentVolumeClaim;
import com.pulumi.kubernetes.core_v1.PersistentVolumeClaimArgs;
import com.pulumi.kubernetes.core_v1.inputs.PersistentVolumeClaimSpecArgs;
import com.pulumi.kubernetes.core_v1.inputs.VolumeResourceRequirementsArgs;
import com.pulumi.resources.CustomResourceOptions;
import java.util.List;
import java.util.ArrayList;
import java.util.Map;
import java.io.File;
import java.nio.file.Files;
import java.nio.file.Paths;

public class App {
    public static void main(String[] args) {
        Pulumi.run(App::stack);
    }

    public static void stack(Context ctx) {
        // ...
        var k8sProvider = new Provider("k8sProvider", ProviderArgs.builder()
            .kubeconfig(cluster.kubeconfig())
            .build());

        var ns = new Namespace("ns", NamespaceArgs.builder()
            .metadata(ObjectMetaArgs.builder()
                .name("nginx")
                .build())
            .build(), CustomResourceOptions.builder()
                .provider(k8sProvider)
                .build());

        var indexContent = new ConfigMap("indexContent", ConfigMapArgs.builder()
            .metadata(ObjectMetaArgs.builder()
                .namespace(ns.metadata().applyValue(metadata -> metadata.name()))
                .build())
            .data(Map.of("index.html", "<html><body><h1>Hello, Pulumi!</h1></body></html>"))
            .build(), CustomResourceOptions.builder()
                .provider(k8sProvider)
                .build());

        var deployment = new Deployment("deployment", DeploymentArgs.builder()
            .metadata(ObjectMetaArgs.builder()
                .namespace(ns.metadata().applyValue(metadata -> metadata.name()))
                .build())
            .spec(DeploymentSpecArgs.builder()
                .selector(LabelSelectorArgs.builder()
                    .matchLabels(Map.of("app", "nginx"))
                    .build())
                .replicas(3)
                .template(PodTemplateSpecArgs.builder()
                    .metadata(ObjectMetaArgs.builder()
                        .labels(Map.of("app", "nginx"))
                        .build())
                    .spec(PodSpecArgs.builder()
                        .containers(ContainerArgs.builder()
                            .name("nginx")
                            .image("nginx")
                            .ports(ContainerPortArgs.builder()
                                .containerPort(80)
                                .build())
                            .volumeMounts(VolumeMountArgs.builder()
                                .name("nginx-index")
                                .mountPath("/usr/share/nginx/html")
                                .build())
                            .build())
                        .volumes(VolumeArgs.builder()
                            .name("nginx-index")
                            .configMap(ConfigMapVolumeSourceArgs.builder()
                                .name(indexContent.metadata().applyValue(metadata -> metadata.name()))
                                .build())
                            .build())
                        .build())
                    .build())
                .build())
            .build(), CustomResourceOptions.builder()
                .provider(k8sProvider)
                .build());

        var service = new Service("service", ServiceArgs.builder()
            .metadata(ObjectMetaArgs.builder()
                .name("nginx")
                .namespace(ns.metadata().applyValue(metadata -> metadata.name()))
                .build())
            .spec(ServiceSpecArgs.builder()
                .selector(Map.of("app", "nginx"))
                .ports(ServicePortArgs.builder()
                    .port(80)
                    .targetPort(80)
                    .build())
                .build())
            .build(), CustomResourceOptions.builder()
                .provider(k8sProvider)
                .dependsOn(deployment)
                .build());

        var ingressClass = new IngressClass("ingressClass", IngressClassArgs.builder()
            .metadata(ObjectMetaArgs.builder()
                .namespace(ns.metadata().applyValue(metadata -> metadata.name()))
                .labels(Map.of("app.kubernetes.io/name", "LoadBalancerController"))
                .name("alb")
                .build())
            .spec(IngressClassSpecArgs.builder()
                .controller("eks.amazonaws.com/alb")
                .build())
            .build(), CustomResourceOptions.builder()
                .provider(k8sProvider)
                .build());

        var ingress = new Ingress("ingress", IngressArgs.builder()
            .metadata(ObjectMetaArgs.builder()
                .namespace(ns.metadata().applyValue(metadata -> metadata.name()))
                .annotations(Map.ofEntries(
                    Map.entry("alb.ingress.kubernetes.io/scheme", "internet-facing"),
                    Map.entry("alb.ingress.kubernetes.io/target-type", "ip")
                ))
                .build())
            .spec(IngressSpecArgs.builder()
                .ingressClassName(ingressClass.metadata().applyValue(metadata -> metadata.name()))
                .rules(IngressRuleArgs.builder()
                    .http(HTTPIngressRuleValueArgs.builder()
                        .paths(HTTPIngressPathArgs.builder()
                            .path("/")
                            .pathType("Prefix")
                            .backend(IngressBackendArgs.builder()
                                .service(IngressServiceBackendArgs.builder()
                                    .name(service.metadata().applyValue(metadata -> metadata.name()))
                                    .port(ServiceBackendPortArgs.builder()
                                        .number(80)
                                        .build())
                                    .build())
                                .build())
                            .build())
                        .build())
                    .build())
                .build())
            .build(), CustomResourceOptions.builder()
                .provider(k8sProvider)
                .build());

        ctx.export("url", ingress.status().applyValue(status -> status.loadBalancer().ingress()[0].hostname()));
    }
}

name: eks-auto-mode-yaml
description: A Pulumi YAML program to deploy a Kubernetes cluster on AWS
runtime: yaml
resources:
  # ...
  k8sProvider:
    type: pulumi:providers:kubernetes
    properties:
      kubeconfig: ${cluster.kubeconfig}
  ns:
    type: kubernetes:core/v1:Namespace
    properties:
      metadata:
        name: nginx
    options:
      provider: ${k8sProvider}
  index-content:
    type: kubernetes:core/v1:ConfigMap
    properties:
      metadata:
        namespace: ${ns.metadata.name}
      data:
        "index.html": "<html><body><h1>Hello, Pulumi!</h1></body></html>"
    options:
      provider: ${k8sProvider}
  deployment:
    type: kubernetes:apps/v1:Deployment
    properties:
      metadata:
        namespace: ${ns.metadata.name}
      spec:
        selector:
          matchLabels:
            app: nginx
        replicas: 3
        template:
          metadata:
            labels:
              app: nginx
          spec:
            containers:
              - name: nginx
                image: nginx
                ports:
                  - containerPort: 80
                volumeMounts:
                  - name: nginx-index
                    mountPath: /usr/share/nginx/html
            volumes:
              - name: nginx-index
                configMap:
                  name: ${index-content.metadata.name}
    options:
      provider: ${k8sProvider}
  service:
    type: kubernetes:core/v1:Service
    properties:
      metadata:
        name: nginx
        namespace: ${ns.metadata.name}
      spec:
        selector:
          app: nginx
        ports:
          - port: 80
            targetPort: 80
    options:
      provider: ${k8sProvider}
      dependsOn:
        - ${deployment}
  ingressClass:
    type: kubernetes:networking.k8s.io/v1:IngressClass
    properties:
      metadata:
        namespace: ${ns.metadata.name}
        labels:
          app.kubernetes.io/name: LoadBalancerController
        name: alb
      spec:
        controller: eks.amazonaws.com/alb
    options:
      provider: ${k8sProvider}
  ingress:
    type: kubernetes:networking.k8s.io/v1:Ingress
    properties:
      metadata:
        namespace: ${ns.metadata.name}
        annotations:
          alb.ingress.kubernetes.io/scheme: internet-facing
          alb.ingress.kubernetes.io/target-type: ip
      spec:
        ingressClassName: ${ingressClass.metadata.name}
        rules:
          - http:
              paths:
                - path: /
                  pathType: Prefix
                  backend:
                    service:
                      name: ${service.metadata.name}
                      port:
                        number: 80
    options:
      provider: ${k8sProvider}
outputs:
  url: ${ingress.status.loadBalancer.ingress[0].hostname}
