Pulumi Kubernetes Operator 2.0

Posted on

A few years ago we released the Pulumi Kubernetes Operator, a cloud-native way to manage and deploy cloud infrastructure using Pulumi from within your Kubernetes environment. We’ve heard your feedback about limitations related to scalability and isolation. Today, we’re excited to announce version 2.0 beta 1 of the Pulumi Kubernetes Operator. We’ve put a new, horizontally scalable architecture in place along with a variety of new security features and customization options. Let’s dig in!

What is the Pulumi Kubernetes Operator?

The Pulumi Kubernetes Operator defines a Kubernetes Custom Resource called pulumi.com/v1/Stack, which represents a Pulumi stack. The Pulumi stack can be authored in any supported Pulumi language (TypeScript, Python, Go, .NET, Java, YAML) and can deploy and manage cloud infrastructure in any supported cloud (AWS, Azure, GCP, Kubernetes and 60+ additional cloud and SaaS providers). The Pulumi Kubernetes Operator triggers cloud deployments based on changes to the Stack Custom Resource or the resources it uses.

As a result, the Pulumi Kubernetes Operator enables users to specify the desired state of their cloud infrastructure by using resources managed directly in their Kubernetes cluster. Modifying those Kubernetes resources will trigger creation, updates, and deletion of the underlying cloud infrastructure that they manage.

For example, the Operator can use the Stack resource below to run a Pulumi program, as defined in a GitHub repository, to deploy NGINX. Subsequent commits to the repository, or changes to the stack’s configuration, will cause the Operator to re-deploy the infrastructure.

apiVersion: pulumi.com/v1
kind: Stack
metadata:
  name: nginx-k8s-stack-production
spec:
  stack: acmecorp/nginx/production
  projectRepo: https://github.com/acmecorp/pulumi-nginx
  commit: 2b0889718d3e63feeb6079ccd5e4488d8601e353

The Pulumi Kubernetes Operator can also be used along with Pulumi’s Kubernetes Provider, which allows Pulumi programs to deploy resources to Kubernetes – either in the same cluster as the Operator, or in another cluster. This can be used to package up complex Kubernetes infrastructure into more abstracted units, to mix Kubernetes and cloud infrastructure into a single unit of deployment, to define how application workloads are deployed into a cluster, or for a wide variety of other use cases. The Pulumi Kubernetes Provider has full support for the Kubernetes API available in every Pulumi language, including support for Helm.

What’s New in Pulumi Kubernetes Operator 2.0?

The 2.0 release is based on a whole new architecture for running Pulumi programs in your Kubernetes cluster. The Operator now allocates a dedicated pod for each Stack to serve as the execution environment for Pulumi stack operations. Previously, all stack operations took place within the Operator’s own pod. This new approach effectively isolates each stack’s compute and memory resources, improves the isolation of secrets, and opens up new customization options.

These pods are referred to as workspace pods. Under the hood, a new Workspace Custom Resource handles the lifecycle of the workspace pod, and is created automatically by the system. A related Update Custom Resource applies a stack operation to a given workspace.

The Stack Custom Resource is still the primary API for using the Pulumi Kubernetes Operator and is largely unchanged. See the Migration section below to understand how to prepare your Stack objects for use with the 2.0 release.

Note: a key limitation of the new system is that cross-namespace references are strictly forbidden. For example, a Stack cannot refer to a Secret in another namespace.

Installation

With the 2.0 release, the supported installation modes are limited to a cluster-wide installation. You’ll need to be a cluster admin to install the Operator. The Operator is able to handle stacks across all the namespaces of your cluster.

We provide three ways to install the Operator:

  1. a Pulumi program (see: deploy/pulumi-operator-yaml/)
  2. a Helm chart (see: deploy/helm/pulumi-operator/)
  3. a simple manifest file (see: deploy/yaml/install.yaml)

Please uninstall any earlier version of the Pulumi Kubernetes Operator, then install the new version using one of the above options. Note that this will remove any existing Stack objects in your cluster, so be sure to export their manifests or have a way to restore them.

Security

To protect your Kubernetes cluster, workspace pods are configured to have minimal permissions as defined by the ‘restricted’ profile of the Pod Security Standards. If necessary, you may configure a stack to use the ‘baseline’ profile.

A Kubernetes ServiceAccount provides an identity for your workspace pod, and we recommend that you create a service account for your stack rather than using the default account. If your Pulumi program uses the Kubernetes provider to manage resources within the cluster, the stack’s service account will need permissions, e.g. a RoleBinding to the ClusterRole named cluster-admin. See “Service Accounts” for more information.

The workspace pod has a RPC endpoint that is used by the Operator to run stack operations. The pod protects the RPC endpoint using Kubernetes RBAC, and for that reason you must bind the ClusterRole named system:auth-delegator to the stack’s service account.

Scalability

Each stack is run in its own “workspace” pod, and so the system scales horizontally to support many stacks. The workspace pod is, by default, configured to use minimal resources when idle, and to ‘burst’ into the unused memory and compute resources of the node during a stack operation. You may customize the resource constraints to fit the needs of your stack by using the workspaceTemplate field. If your Kubernetes cluster has high utilization, we recommend increasing the resource requests and limits. See “Pod Quality of Service Classes” for more information.

The pod is not discarded at the end of a stack operation, instead it remains in-place unless the stack is deleted. We’re considering introducing the option to clean up the workspace pod after each operation to enable you to make a trade-off decision between performance and efficiency. Please let us know if this is something you’d like to see!

Stability

A Kubernetes cluster is a dynamic environment where a given pod may be terminated at any time, e.g. due to maintenance operations, unplanned node events, or resource pressure. This can cause problems for ongoing stack operations, and historically may cause a stack to become “locked”, necessitating manual intervention with the use of pulumi cancel.

The new system has been made more resilient by being responsive to pod termination requests. It responds by proactively sending CTRL-C to the ongoing stack operation, to gracefully wind down the operation.

If your stack has a lot of resources, consider increasing the pod’s termination grace period (default: 10 minutes).

Customization and Extensibility

Let’s discuss how to customize the stack’s environment. The Stack resource continues to provide ways to set environment variables and to set stack configuration values. What’s new is the ability to:

  • use a custom Docker image for your stack environment
  • set the stack environment’s compute and storage resources
  • attach volumes, init containers, and sidecars

This is accomplished using the workspaceTemplate field of the Stack resource, to customize the Workspace object that is automatically created by the system for a given stack.

By default, the system uses the official pulumi/pulumi Docker image. You may wish to create your own Docker image that is based on it, e.g. to pre-install your program’s dependencies (using pulumi install) for performance reasons. Be prepared to update the image over time to incorporate the latest version of the Pulumi CLI.

One use case for an extra init container is to customize how your program’s sources are obtained. The system supports Git repositories and Flux sources out-of-the-box, but you have the option of handling it yourself, e.g. to generate a Pulumi project or to download from another source. You simply inject an init container, mount the share volume to /share, and then place the project files into /share/workspace. Contact us to learn more.

Here’s an example of a stack with some customizations applied:

apiVersion: pulumi.com/v1
kind: Stack
metadata:
  name: my-stack
spec:
  ...
  workspaceTemplate:
    spec:
      image: example/pulumi-with-dependencies:v3.334
      podTemplate:
        metadata:
          labels:
            example.com/mylabel: bar
        spec:
          terminationGracePeriodSeconds: 3600
          tolerations:
          - key: "example.com/foo"
            operator: "Exists"
            effect: "NoSchedule"
          initContainers:
          - name: extra # add an extra init container
            image: busybox
            command: ["sh", "-c", "echo 'Hello, extra init container!'"]
            securityContext:
              allowPrivilegeEscalation: false
              capabilities:
                add:
                - NET_BIND_SERVICE
                drop:
                - ALL
            volumeMounts:
            - name: share
              mountPath: /share
          containers:
            - name: pulumi # customize the main container where Pulumi stack operations are executed
            volumeMounts:
            - name: oidc-token
              mountPath: /var/run/secrets/pulumi
          volumes:
          - name: oidc-token # mount an OIDC token
            projected:
              sources:
              - serviceAccountToken:
                  audience: urn:pulumi:org:ORG_NAME
                  path: token
                  expirationSeconds: 3600

Operability

Since each stack has its own long-running pod, you may inspect the console output for a given stack by accessing the pod logs. The pod’s name is based on the stack name; for example, given a stack named my-stack, look for a pod named my-stack-workspace-0. We recommend the stern tool to access pod logs. See “Pod and container logs” for more information.

If you need to run an interactive Pulumi command for your stack, e.g. pulumi import, exec into the workspace pod. Navigate to the /share/workspace directory and you should find your program there.

Walkthrough

Here’s a quick demonstration of the new system. Let’s deploy the random-yaml program from the pulumi/examples repository.

We’ll be using Flux for this demonstration; to follow along, install Flux (see “Installation”).

Setup the GitRepository Source

For this demonstration, we’ll use Flux to clone and cache the pulumi/examples repository, since it is a large repository and the Flux cache provides a big performance improvement. The system works well without Flux too.

apiVersion: source.toolkit.fluxcd.io/v1
kind: GitRepository
metadata:
  name: pulumi-examples
  namespace: default
spec:
  interval: 24h
  ref:
    branch: master
  url: https://github.com/pulumi/examples

Install a Pulumi Access Token

Create a Secret containing a Pulumi access token to be used by the stack to authenticate to Pulumi Cloud. Follow these instructions to create a personal, organization, or team access token.

Store the access token into a Kubernetes Secret. Here’s an easy way to create a Secret named pulumi-api-secret. Replace TOKEN with the token that you created.

$ kubectl create secret generic pulumi-api-secret -n default --from-literal=accessToken=TOKEN

Create a Service Account

The stack requires a Kubernetes service account with a binding to the system:auth-delegator cluster role.

If you don’t have admin permissions in your Kubernetes cluster, ask your administrator to create the service account for you. The Pulumi Kubernetes Operator installer also pre-creates a usable ServiceAccount named pulumi in the default namespace.

apiVersion: v1
kind: ServiceAccount
metadata:
  name: random-yaml
  namespace: default
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: random-yaml:system:auth-delegator
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: system:auth-delegator
subjects:
- kind: ServiceAccount
  name: random-yaml
  namespace: default

Create the Stack

Let’s apply a Stack object to deploy the program. Note that the specification makes reference to the GitRepository (pulumi-examples), the Secret (pulumi-api-secret), and the ServiceAccount (random-yaml) created earlier.

apiVersion: pulumi.com/v1
kind: Stack
metadata:
  name: random-yaml
  namespace: default
spec:
  serviceAccountName: random-yaml
  fluxSource:
    sourceRef:
      apiVersion: source.toolkit.fluxcd.io/v1
      kind: GitRepository
      name: pulumi-examples
    dir: random-yaml/
  stack: dev
  refresh: true
  continueResyncOnCommitMatch: true
  resyncFrequencySeconds: 300
  destroyOnFinalize: true
  envRefs:
    PULUMI_ACCESS_TOKEN:
      type: Secret
      secret:
        name: pulumi-api-secret
        key: accessToken

This stack is configured to deploy immediately and to resync every five minutes. The term “resync” means to execute pulumi up, which is useful for stacks that produce resources or outputs that require a periodic update. Without resync, pulumi up runs whenever a new commit is pushed to the repository.

Observe the Workspace

The system automatically creates a Workspace object named random-yaml to provision an execution environment. Let’s watch as the workspace’s status progresses towards readiness. For this demonstration, we’ll use the --watch flag to observe the status updates:

$ kubectl get workspace --watch
NAME          IMAGE                           READY   ADDRESS
random-yaml   pulumi/pulumi:3.134.1-nonroot
random-yaml   pulumi/pulumi:3.134.1-nonroot   False
random-yaml   pulumi/pulumi:3.134.1-nonroot   False   random-yaml-workspace.default.svc.cluster.local:50051
random-yaml   pulumi/pulumi:3.134.1-nonroot   False   random-yaml-workspace.default.svc.cluster.local:50051
random-yaml   pulumi/pulumi:3.134.1-nonroot   True    random-yaml-workspace.default.svc.cluster.local:50051

Observe the Updates

Once the workspace is ready, the system proceeds to run a periodic update. Each update is represented by an Update object. Let’s watch the progression across three updates:

$ kubectl get update --watch
NAME                   WORKSPACE     PROGRESSING   FAILED   COMPLETE   URL
random-yaml-5kmn7dcm   random-yaml
random-yaml-5kmn7dcm   random-yaml   True          False    False
random-yaml-5kmn7dcm   random-yaml   False         False    True       https://app.pulumi.com/eron-pulumi-corp/random/dev/updates/1
random-yaml-rftp8gj8   random-yaml
random-yaml-rftp8gj8   random-yaml   True          False    False
random-yaml-rftp8gj8   random-yaml   False         False    True       https://app.pulumi.com/eron-pulumi-corp/random/dev/updates/2
random-yaml-sjpw5hm8   random-yaml
random-yaml-sjpw5hm8   random-yaml   True          False    False
random-yaml-sjpw5hm8   random-yaml   False         False    True       https://app.pulumi.com/eron-pulumi-corp/random/dev/updates/3

Observe the Stack

The Stack object maintains a status block showing the result of the latest attempt and whether an update is currently running. Taking a look, we see a successful outcome.

$ kubectl get stack random-yaml -oyaml
apiVersion: pulumi.com/v1
kind: Stack
...
status:
  conditions:
  - lastTransitionTime: "2024-10-17T20:41:49Z"
    message: the stack has been processed and is up to date
    reason: ProcessingCompleted
    status: "True"
    type: Ready
  lastUpdate:
    failures: 0
    generation: 2
    lastAttemptedCommit: sha256:44d554df090dcdeb9bae908cd38155c8c93db05f64dc72982027e8e1294af0d3
    lastResyncTime: "2024-10-17T20:41:49Z"
    lastSuccessfulCommit: sha256:44d554df090dcdeb9bae908cd38155c8c93db05f64dc72982027e8e1294af0d3
    name: random-yaml-sjpw5hm8
    permalink: https://app.pulumi.com/eron-pulumi-corp/random/dev/updates/3
    state: succeeded
    type: up
  observedGeneration: 2
  outputs:
    password: '[secret]'

Delete the Stack

To complete the demonstration, let’s delete the Stack object. Because spec.destroyOnFinalize is enabled, deleting the object causes the Pulumi stack to be destroyed. That is, the stack resources are deleted.

$ kubectl delete stack random-yaml
stack.pulumi.com "random-yaml" deleted

$ kubectl get workspace
No resources found in default namespace.

$ kubectl get update
No resources found in default namespace.

Migration

Ready to leverage these new features? Let’s quickly cover how to migrate your existing setup to Pulumi Kubernetes Operator 2.0.

The Stack custom resource continues to be the primary way to use the Pulumi Kubernetes Operator, and your existing stack definitions should continue to work after you follow a simple migration procedure:

  1. Create a ServiceAccount and associated ClusterRoleBinding as shown in the Security section.
  2. If your stack uses the Pulumi Kubernetes Provider, create a RoleBinding or a ClusterRoleBinding to grant the necessary permissions, e.g. to the well-known ClusterRole named cluster-admin. See “Using RBAC Authorization” for more information.
  3. Edit your Stack manifest(s) to use the service account, by setting the spec.serviceAccountName field.
  4. Double-check that your Stack objects do not make use of cross-namespace references.

If you’re using a private Git repository as your program source, use the Stack’s secretRefs field to reference Git credentials. SSH-based access to the repository may require a custom image with your host’s public key(s) baked in. Contact us to learn more.

If you’re using Flux integration, there’s an additional step to be performed by your cluster administrator. Please create a NetworkPolicy to allow the workspace pods to access the Flux source controller. Here’s the manifest to be applied:

apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-pulumi-fetch-flux-artifacts
  namespace: flux-system
spec:
  podSelector:
    matchLabels:
      app: source-controller
  ingress:
    - ports:
        - protocol: TCP
          port: http
      from:
        - namespaceSelector:
            matchLabels:
              kubernetes.io/metadata.name: default
        - podSelector:
            matchLabels:
              app.kubernetes.io/managed-by: pulumi-kubernetes-operator
              app.kubernetes.io/name: pulumi
              app.kubernetes.io/component: workspace
  policyTypes:
    - Ingress

Conclusion

The Pulumi Kubernetes Operator is a great way to deploy and manage cloud infrastructure from within your Kubernetes environment. With the 2.0 release, we’ve solved the scalability and isolation limitations that affected early adopters. You can get started with the Pulumi Kubernetes Operator today. Please join us on the #kubernetes channel of the Pulumi Community Slack workspace to give feedback, and enjoy!
