Introducing Resource Transforms: Enhancing Flexibility for Packaged Component Resources
Posted on
Pulumi has supported a Transformations system for a number of years now. This has proved to be a powerful and flexible escape hatch for modifying resource properties and options across your entire program. For example, you could use Transformations to automatically apply tags to all taggable resources in your program, including the children of component resources.
However, there is one major limitation with the existing Transformations system: it isn’t able to transform the children of packaged component resources, such as those in awsx and eks. This limitation is due to the fact that packaged component resources are created in a separate provider process and Transformations only work with resources created in your program’s process.
To address this limitation we’re introducing a new system called Transforms, which works with all resources, including packaged component resources and their children. The new Transforms system is intended to fully replace the old Transformations system (we plan to deprecate the old system in the future).
Here’s an example that demonstrates adding tags to all Subnet
child resources created by the Vpc
packaged component:
import * as pulumi from "@pulumi/pulumi";
import * as awsx from "@pulumi/awsx";
const myTags = { test: "TEST" };
pulumi.runtime.registerResourceTransform(args => {
if (args.type === "aws:ec2/subnet:Subnet") {
const tags = pulumi.output(args.props.tags || {});
args.props.tags = tags.apply(t => ({ ...t, ...myTags }));
return { props: args.props, opts: args.opts };
}
return undefined;
});
const vpc = new awsx.ec2.Vpc("test");
import pulumi
from pulumi_awsx import ec2
my_tags = { "test": "TEST" }
def tag_transform(args):
if args.type_ == "aws:ec2/subnet:Subnet":
tags = pulumi.Output.from_input(args.props.get("tags", {}))
args.props["tags"] = tags.apply(lambda v: {**v, **my_tags})
return pulumi.ResourceTransformResult(args.props, args.opts)
pulumi.runtime.register_resource_transform(tag_transform)
my_vpc = ec2.Vpc("my-vpc")
package main
import (
"context"
"github.com/pulumi/pulumi-awsx/sdk/v2/go/awsx/ec2"
"github.com/pulumi/pulumi/sdk/v3/go/pulumi"
)
func main() {
pulumi.Run(func(ctx *pulumi.Context) error {
myTags := map[string]string{"test": "TEST"}
err := ctx.RegisterResourceTransform(func(_ context.Context, args *pulumi.ResourceTransformArgs) *pulumi.ResourceTransformResult {
if args.Type == "aws:ec2/subnet:Subnet" {
tags, ok := args.Props["tags"].(pulumi.StringMapInput)
if !ok {
tags = pulumi.StringMap{}
}
args.Props["tags"] = tags.ToStringMapOutput().ApplyT(func(m map[string]string) map[string]string {
result := make(map[string]string)
for k, v := range m {
result[k] = v
}
for k, v := range myTags {
result[k] = v
}
return result
})
return &pulumi.ResourceTransformResult{
Props: args.Props,
Opts: args.Opts,
}
}
return nil
})
if err != nil {
return err
}
_, err = ec2.NewVpc(ctx, "test", nil)
if err != nil {
return err
}
return nil
})
}
using System;
using System.Collections.Immutable;
using Pulumi;
using Pulumi.Awsx.Ec2;
await Deployment.RunAsync<MyStack>();
class MyStack : Stack
{
public MyStack() : base(new StackOptions
{
ResourceTransforms =
{
async (args, _) => {
var myTags = ImmutableDictionary.Create<string, object>()
.Add("test", "Test");
if (args.Type == "aws:ec2/subnet:Subnet")
{
InputMap<object> tags =
args.Args.TryGetValue("tags", out var tagsValue) && tagsValue is not null ?
tagsValue is Output<ImmutableDictionary<string, object>> tagsOutput ? tagsOutput :
tagsValue is ImmutableDictionary<string, object> tagsDictionary ? tagsDictionary :
throw new InvalidOperationException($"Unexpected tags type: {tagsValue.GetType()}") :
ImmutableDictionary<string, object>.Empty;
tags = tags.Apply(t => t.SetItems(myTags));
return new(args.Args.SetItem("tags", tags), args.Options);
}
return null;
},
}
})
{
var vpc = new Vpc("test");
}
}
Using the new Transforms system is similar to the old system, but there are some differences between the two systems. A guide on Migrating from Transformations to Transforms is available to help transition to the new system.
We’re excited to make it possible to transform all resources in your program, including those from packaged components. If you have any questions or feedback, please don’t hesitate to reach out to us on Slack.
