New: ConfigGroup, ConfigFile resources for Java, YAML SDKs

The Pulumi Kubernetes provider makes it easy to deploy Kubernetes resources to your cluster, giving you options based on how your application or workload is packaged. The options include strongly-typed resources for standard Kubernetes types, Helm charts, Kustomizations, and Kubernetes manifests.

In v4.10, we leveled up the support for working with Kubernetes manifests with the introduction of the yaml/v2 package. The package provides new implementations of the ConfigGroup and ConfigFile resources, expanding support to the Pulumi Java SDK and to Pulumi YAML. The new implementations are also smarter about applying the objects in the correct order.

Please note that these resources are in a preview stage of maturity, as we continue to round out the feature set. These new resources are provided side-by-side with the existing implementations.

Let’s explore how it’s easier than ever to deploy diverse Kubernetes workloads using Pulumi.

kubernetes.yaml/v2.ConfigGroup

The ConfigGroup resource creates a set of Kubernetes objects from Kubernetes manifests and/or object literals. The Kubernetes manifest may be supplied using any combination of the following methods:

1. a filename or a list of filenames.
2. a file pattern or a list of file patterns.
3. a literal string containing YAML or JSON text.
4. a literal object or a list of objects.

The ConfigGroup resource accepts the following input properties:

Note that all objects defined within the manifest must have a metadata.name field; Pulumi autonaming is not supported.

See the API Reference documentation for more information.

Manifest Files

Here’s an example of applying a Kubernetes manifest file to your cluster.

name: demo-cg-1
runtime: yaml
resources:
  cg:
    type: kubernetes:yaml/v2:ConfigGroup
    properties:
      files:
      - ./manifest.yaml

YAML Text

Here’s how to apply an inline manifest.

name: demo-cg-2
runtime: yaml
resources:
  cg:
    type: kubernetes:yaml/v2:ConfigGroup
    properties:
      yaml: |
        apiVersion: v1
        kind: ConfigMap
        metadata:
          name: my-server-config
        data:
          altGreeting: "Good Morning!"
        ---
        apiVersion: v1
        kind: Secret
        metadata:
          name: my-dotfile-secret
        data:
          .secret-file: dmFsdWUtMg0KDQo=

Object Literals

With ConfigGroup it’s easy to define a Kubernetes object using Pulumi property values. Let’s create a Kubernetes namespace and deploy a custom resource into that namespace.

name: demo-cg-3
runtime: yaml
resources:
  ns:
    type: kubernetes:core/v1:Namespace
  cg:
    type: kubernetes:yaml/v2:ConfigGroup
    properties:
      objs:
      - apiVersion: stable.example.com/v1
        kind: CronTab
        metadata:
          namespace: ${ns.metadata.name}
          name: my-crontab
        spec:
          cronSpec: "* * * * */5"

This feature is expecially useful for Pulumi YAML, since the apiextensions.k8s.io:CustomResource resource isn’t supported yet (see pulumi-kubernetes#2787).

Resource Ordering

The ConfigGroup resource automatically detects dependencies between resources in the manifest(s). For example, it knows to install namespaces and Custom Resource Definitions (CRDs) first.

Use the config.kubernetes.io/depends-on annotation to declare an explicit resource dependency. The annotation accepts a list of resource references, delimited by commas.

It consists of the group, kind, name, and optionally the namespace, delimited by forward slashes.

For resources in the “core” group, the empty string is used instead (for example: /namespaces/test/Pod/pod-a).

Resource Prefixes

The purpose of the resource prefix is to ensure the uniqueness of child resource names, as described in Pulumi: Resource Names. The best practice is to use the component name as a prefix, and now that’s the default behavior.

Note that the resource prefix is not applied to the Kubernetes object names.

Transformation Support

The Kubernetes provider generally supports resource transformations, e.g. to apply a resource alias or to apply an object name prefix or object label. Transformations aren’t yet possible with the new ConfigGroup resource (see pulumi/pulumi#12996), but stay tuned as we work towards a GA release later this year.

kubernetes.yaml/v2.ConfigFile

The ConfigFile resource creates a set of Kubernetes objects from a Kubernetes manifest. While ConfigGroup offers a superset of functionality, the ConfigFile gives a concise way to apply a specific manifest.

The ConfigFile resource accepts the following input properties:

See the API Reference documentation for more information.

Manifest File

Here’s an example of applying a Kubernetes manifest file to your cluster:

name: demo-cg-1
runtime: yaml
resources:
  cf:
    type: kubernetes:yaml/v2:ConfigFile
    properties:
      file: ./manifest.yaml

Example: Certificate Manager

Here’s a complete example of how to install and use cert-manager using ConfigGroup resources.

name: cert-manager
runtime: yaml
description: Installs cert-manager.  See https://cert-manager.io/docs/installation/kubectl/ for details.
variables: {}
resources:
  install:
    type: kubernetes:yaml/v2:ConfigGroup
    properties:
      files:
      - https://github.com/cert-manager/cert-manager/releases/download/v1.14.4/cert-manager.yaml
  test:
    type: kubernetes:yaml/v2:ConfigGroup
    options:
      dependsOn:
      - ${install}
    properties:
      yaml: |
        apiVersion: v1
        kind: Namespace
        metadata:
          name: cert-manager-test
        ---
        apiVersion: cert-manager.io/v1
        kind: Issuer
        metadata:
          name: test-selfsigned
          namespace: cert-manager-test
        spec:
          selfSigned: {}
        ---
        apiVersion: cert-manager.io/v1
        kind: Certificate
        metadata:
          name: selfsigned-cert
          namespace: cert-manager-test
          annotations:
            config.kubernetes.io/depends-on: cert-manager.io/namespaces/cert-manager-test/Issuer/test-selfsigned
        spec:
          dnsNames:
            - example.com
          secretName: selfsigned-cert-tls
          issuerRef:
            name: test-selfsigned

Conclusion

With the new resources in yaml/v2, we’re excited to enable new scenarios in Pulumi YAML and the Pulumi Java SDK. Stay tuned for new editions of the Chart and Directory resources, coming soon.

This is part of a broad initiative to use Multi-Language Component (MLC) technology to offer a consistent experience across the Pulumi SDKs. See pulumi-kubernetes#1971 for details.
