The Pulumi Kubernetes provider makes it easy to deploy Kubernetes resources to your cluster, giving you options based on how your application or workload is packaged. The options include strongly-typed resources for standard Kubernetes types, Helm charts, Kustomizations, and Kubernetes manifests.
In v4.10, we leveled up the support for working with Kubernetes manifests with the introduction of the yaml/v2
package.
The package provides new implementations of the ConfigGroup
and ConfigFile
resources, expanding support to the
Pulumi Java SDK and to Pulumi YAML. The new implementations are also smarter about applying the objects in the correct order.
Please note that these resources are in a preview stage of maturity, as we continue to round out the feature set. These new resources are provided side-by-side with the existing implementations.
Let’s explore how it’s easier than ever to deploy diverse Kubernetes workloads using Pulumi.
kubernetes.yaml/v2.ConfigGroup
The ConfigGroup
resource creates a set of Kubernetes objects from Kubernetes manifests and/or object literals.
The Kubernetes manifest may be supplied using any combination of the following methods:
- a filename or a list of filenames.
- a file pattern or a list of file patterns.
- a literal string containing YAML or JSON text.
- a literal object or a list of objects.
The ConfigGroup
resource accepts the following input properties:
Property | Description |
---|---|
files | Set of files, patterns and/or URLs to Kubernetes manifest files. Filenames containing any of the characters * , ? , and [ are treated as patterns. |
objs | Set of Kubernetes objects. |
yaml | A Kubernetes manifest as a YAML or JSON string. |
resourcePrefix | A prefix for auto-generated names of the child resources. Defaults to the ConfigGroup name. |
skipAwait | Skips over the readiness checks on the child resources. |
Note that all objects defined within the manifest must have a metadata.name
field;
Pulumi autonaming is not supported.
See the API Reference documentation for more information.
Manifest Files
Here’s an example of applying a Kubernetes manifest file to your cluster.
name: demo-cg-1
runtime: yaml
resources:
cg:
type: kubernetes:yaml/v2:ConfigGroup
properties:
files:
- ./manifest.yaml
YAML Text
Here’s how to apply an inline manifest.
name: demo-cg-2
runtime: yaml
resources:
cg:
type: kubernetes:yaml/v2:ConfigGroup
properties:
yaml: |
apiVersion: v1
kind: ConfigMap
metadata:
name: my-server-config
data:
altGreeting: "Good Morning!"
---
apiVersion: v1
kind: Secret
metadata:
name: my-dotfile-secret
data:
.secret-file: dmFsdWUtMg0KDQo=
Object Literals
With ConfigGroup
it’s easy to define a Kubernetes object using Pulumi property values. Let’s create a
Kubernetes namespace and deploy a custom resource into that namespace.
name: demo-cg-3
runtime: yaml
resources:
ns:
type: kubernetes:core/v1:Namespace
cg:
type: kubernetes:yaml/v2:ConfigGroup
properties:
objs:
- apiVersion: stable.example.com/v1
kind: CronTab
metadata:
namespace: ${ns.metadata.name}
name: my-crontab
spec:
cronSpec: "* * * * */5"
This feature is expecially useful for Pulumi YAML, since the apiextensions.k8s.io:CustomResource
resource isn’t
supported yet (see pulumi-kubernetes#2787).
Resource Ordering
The ConfigGroup
resource automatically detects dependencies between resources in the manifest(s).
For example, it knows to install namespaces and Custom Resource Definitions (CRDs) first.
Use the config.kubernetes.io/depends-on
annotation to declare an explicit resource dependency.
The annotation accepts a list of resource references, delimited by commas.
It consists of the group, kind, name, and optionally the namespace, delimited by forward slashes.
Resource Scope | Format |
---|---|
namespace-scoped | <group>/namespaces/<namespace>/<kind>/<name> |
cluster-scoped | <group>/<kind>/<name> |
For resources in the “core” group, the empty string is used instead (for example: /namespaces/test/Pod/pod-a
).
Resource Prefixes
The purpose of the resource prefix is to ensure the uniqueness of child resource names, as described in Pulumi: Resource Names. The best practice is to use the component name as a prefix, and now that’s the default behavior.
Note that the resource prefix is not applied to the Kubernetes object names.
Transformation Support
The Kubernetes provider generally supports resource transformations, e.g. to apply a resource alias or
to apply an object name prefix or object label. Transformations aren’t yet possible with the
new ConfigGroup
resource (see pulumi/pulumi#12996),
but stay tuned as we work towards a GA release later this year.
kubernetes.yaml/v2.ConfigFile
The ConfigFile
resource creates a set of Kubernetes objects from a Kubernetes manifest. While ConfigGroup
offers
a superset of functionality, the ConfigFile
gives a concise way to apply a specific manifest.
The ConfigFile
resource accepts the following input properties:
Property | Description |
---|---|
file | A file or URL to a Kubernetes manifest file. |
resourcePrefix | A prefix for auto-generated names of the child resources. Defaults to the ConfigFile name. |
skipAwait | Skips over the readiness checks on the child resources. |
See the API Reference documentation for more information.
Manifest File
Here’s an example of applying a Kubernetes manifest file to your cluster:
name: demo-cg-1
runtime: yaml
resources:
cf:
type: kubernetes:yaml/v2:ConfigFile
properties:
file: ./manifest.yaml
Example: Certificate Manager
Here’s a complete example of how to install and use cert-manager using ConfigGroup
resources.
name: cert-manager
runtime: yaml
description: Installs cert-manager. See https://cert-manager.io/docs/installation/kubectl/ for details.
variables: {}
resources:
install:
type: kubernetes:yaml/v2:ConfigGroup
properties:
files:
- https://github.com/cert-manager/cert-manager/releases/download/v1.14.4/cert-manager.yaml
test:
type: kubernetes:yaml/v2:ConfigGroup
options:
dependsOn:
- ${install}
properties:
yaml: |
apiVersion: v1
kind: Namespace
metadata:
name: cert-manager-test
---
apiVersion: cert-manager.io/v1
kind: Issuer
metadata:
name: test-selfsigned
namespace: cert-manager-test
spec:
selfSigned: {}
---
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
name: selfsigned-cert
namespace: cert-manager-test
annotations:
config.kubernetes.io/depends-on: cert-manager.io/namespaces/cert-manager-test/Issuer/test-selfsigned
spec:
dnsNames:
- example.com
secretName: selfsigned-cert-tls
issuerRef:
name: test-selfsigned
Conclusion
With the new resources in yaml/v2
, we’re excited to enable new scenarios in Pulumi YAML and the Pulumi Java SDK.
Stay tuned for new editions of the Chart
and Directory
resources, coming soon.
This is part of a broad initiative to use Multi-Language Component (MLC) technology to offer a consistent experience across the Pulumi SDKs. See pulumi-kubernetes#1971 for details.
Check out the following links to learn more about Pulumi Kubernetes today!
