Pulumi Import: Generate IaC for Existing Cloud Resources

Most infrastructure projects require working with existing cloud resources, either by building on top of existing resources or adopting existing resources under management with a new and more robust infrastructure provisioning solution.

In June 2019, Pulumi introduced the ability to import existing infrastructure resources to be under Pulumi management no matter how you’ve provisioned these resources — manually in your cloud provider’s console or CLI, using an infrastructure as code tool like Terraform or AWS CloudFormation. Today, we are happy to announce a richer resource import experience.

As of v2.12.0, Pulumi has introduced a pulumi import command. This command will import the cloud resource into the Pulumi state and generate the code for the user’s Pulumi program in the appropriate language.

The Anatomy of the Import Command

No matter how resources have been provisioned in the cloud, Pulumi enables you to adopt and manage those resources as part of your infrastructure project. The pulumi import command is made of the following:

pulumi import [type] [name] [id]

When Pulumi performs an import, the resource is added to the Pulumi state, it is marked as a protected resource (by default), and it will emit the generated code that the user can add to their program before running a pulumi up. The resources are marked as protected to ensure that imported infrastructure is not accidentally deleted if the user forgets to include the code for the resource in their program before doing a deployment.

Importing an S3 Bucket

A resource needs to be imported into an existing Pulumi project. Let’s consider that a user wants to import an S3 bucket manually created in their AWS Account. To do this, we can execute the following command:

pulumi import aws:s3/bucket:Bucket infra-logs company-infra-logs

This command instructs Pulumi to import the S3 bucket called company-infra-logs with the Pulumi resource name infra-logs. The import command will output as follows:

The user can then see the generated code they need to use as part of their application. I imported this resource into a TypeScript application:

import * as pulumi from "@pulumi/pulumi";
import * as aws from "@pulumi/aws";

const demo = new aws.s3.Bucket("infra-logs", {
    acl: "private",
    bucket: "company-infra-logs",
    forceDestroy: false,
}, {
    protect: true,
});
import pulumi
import pulumi_aws as aws

demo = aws.s3.Bucket("infra-logs",
    acl="private",
    bucket="company-infra-logs",
    force_destroy=False,
    opts=ResourceOptions(protect=True))
package main

import (
	"github.com/pulumi/pulumi-aws/sdk/v3/go/aws/s3"
	"github.com/pulumi/pulumi/sdk/v2/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		_, err := s3.NewBucket(ctx, "infra-logs", &s3.BucketArgs{
			Acl:          pulumi.String("private"),
			Bucket:       pulumi.String("company-infra-logs"),
			ForceDestroy: pulumi.Bool(false),
		}, pulumi.Protect(true))
		if err != nil {
			return err
		}
		return nil
	})
}
using Pulumi;
using Aws = Pulumi.Aws;

class MyStack : Stack
{
    public MyStack()
    {
        var demo = new Aws.S3.Bucket("infra-logs", new Aws.S3.BucketArgs
        {
            Acl = "private",
            Bucket = "company-infra-logs",
            ForceDestroy = false,
        }, new CustomResourceOptions
        {
            Protect = true,
        });
    }

}

This is valid Pulumi application code and can be added to your Pulumi application. Notice that the Pulumi resource is marked as protect: true. This means Pulumi will not delete that resource unless this protection attribute is removed from the resource. If this code is not added to your Pulumi application, then a Pulumi update will return the following:

Diagnostics:
  pulumi:pulumi:Stack (import-example-dev):
    error: preview failed

  aws:s3:Bucket (demo):
    error: Preview failed: refusing to delete protected resource 'urn:pulumi:dev::import-example::aws:s3/bucket:Bucket::infra-logs'

Importing Multiple Resources

Should a user need to import multiple resources to be managed by Pulumi, the CLI import command can handle this scenario for us. This is helpful when using the pulumi import command as part of scripting larger bulk imports of cloud resource:

{
	"resources": [{
			"type": "aws:ec2/vpc:Vpc",
			"name": "application-vpc",
			"id": "vpc-0ad77710973388316"
		},
		{
			"type": "aws:ec2/subnet:Subnet",
			"name": "public-1",
			"id": "subnet-0fb5fdff92b9e5a3b"
		},
		{
			"type": "aws:ec2/subnet:Subnet",
			"name": "private-1",
			"id": "subnet-0a39d25dd9f7b7808"
		}
	]
}

We can then run the command:

pulumi import -f resources.json

We can see the resultant code generation:

import * as pulumi from "@pulumi/pulumi";
import * as aws from "@pulumi/aws";

const application_vpc = new aws.ec2.Vpc("application-vpc", {
    assignGeneratedIpv6CidrBlock: false,
    cidrBlock: "172.16.0.0/16",
    enableDnsSupport: true,
    instanceTenancy: "default",
    tags: {
        Name: "pulumi-vpc",
        Owner: "pulumi",
        Project: "pulumi-k8s-aws-cluster",
    },
}, {
    protect: true,
});
const public_1 = new aws.ec2.Subnet("public-1", {
    assignIpv6AddressOnCreation: false,
    cidrBlock: "172.16.32.0/19",
    mapPublicIpOnLaunch: true,
    tags: {
        Name: "pulumi-vpc-public-1",
        Owner: "pulumi",
        Project: "pulumi-k8s-aws-cluster",
        "kubernetes.io/role/elb": "1",
        type: "public",
    },
    vpcId: "vpc-0ad77710973388316",
}, {
    protect: true,
});
const private_1 = new aws.ec2.Subnet("private-1", {
    assignIpv6AddressOnCreation: false,
    cidrBlock: "172.16.160.0/19",
    mapPublicIpOnLaunch: false,
    tags: {
        Name: "pulumi-vpc-private-1",
        Owner: "pulumi",
        Project: "pulumi-k8s-aws-cluster",
        "kubernetes.io/role/internal-elb": "1",
        type: "private",
    },
    vpcId: "vpc-0ad77710973388316",
}, {
    protect: true,
});
import pulumi
import pulumi_aws as aws

application_vpc = aws.ec2.Vpc("application-vpc",
    assign_generated_ipv6_cidr_block=False,
    cidr_block="172.16.0.0/16",
    enable_dns_support=True,
    instance_tenancy="default",
    tags={
        "Name": "pulumi-vpc",
        "Owner": "pulumi",
        "Project": "pulumi-k8s-aws-cluster",
    },
    opts=ResourceOptions(protect=True))
public_1 = aws.ec2.Subnet("public-1",
    assign_ipv6_address_on_creation=False,
    cidr_block="172.16.32.0/19",
    map_public_ip_on_launch=True,
    tags={
        "Name": "pulumi-vpc-public-1",
        "Owner": "pulumi",
        "Project": "pulumi-k8s-aws-cluster",
        "kubernetes.io/role/elb": "1",
        "type": "public",
    },
    vpc_id="vpc-0ad77710973388316",
    opts=ResourceOptions(protect=True))
private_1 = aws.ec2.Subnet("private-1",
    assign_ipv6_address_on_creation=False,
    cidr_block="172.16.160.0/19",
    map_public_ip_on_launch=False,
    tags={
        "Name": "pulumi-vpc-private-1",
        "Owner": "pulumi",
        "Project": "pulumi-k8s-aws-cluster",
        "kubernetes.io/role/internal-elb": "1",
        "type": "private",
    },
    vpc_id="vpc-0ad77710973388316",
    opts=ResourceOptions(protect=True))
package main

import (
	"github.com/pulumi/pulumi-aws/sdk/v3/go/aws/ec2"
	"github.com/pulumi/pulumi/sdk/v2/go/pulumi"
)

func main() {
	pulumi.Run(func(ctx *pulumi.Context) error {
		_, err := ec2.NewVpc(ctx, "application_vpc", &ec2.VpcArgs{
			AssignGeneratedIpv6CidrBlock: pulumi.Bool(false),
			CidrBlock:                    pulumi.String("172.16.0.0/16"),
			EnableDnsSupport:             pulumi.Bool(true),
			InstanceTenancy:              pulumi.String("default"),
			Tags: pulumi.StringMap{
				"Name":    pulumi.String("pulumi-vpc"),
				"Owner":   pulumi.String("pulumi"),
				"Project": pulumi.String("pulumi-k8s-aws-cluster"),
			},
		}, pulumi.Protect(true))
		if err != nil {
			return err
		}
		_, err = ec2.NewSubnet(ctx, "public_1", &ec2.SubnetArgs{
			AssignIpv6AddressOnCreation: pulumi.Bool(false),
			CidrBlock:                   pulumi.String("172.16.32.0/19"),
			MapPublicIpOnLaunch:         pulumi.Bool(true),
			Tags: pulumi.StringMap{
				"Name":                   pulumi.String("pulumi-vpc-public-1"),
				"Owner":                  pulumi.String("pulumi"),
				"Project":                pulumi.String("pulumi-k8s-aws-cluster"),
				"kubernetes.io/role/elb": pulumi.String("1"),
				"type":                   pulumi.String("public"),
			},
			VpcId: pulumi.String("vpc-0ad77710973388316"),
		}, pulumi.Protect(true))
		if err != nil {
			return err
		}
		_, err = ec2.NewSubnet(ctx, "private_1", &ec2.SubnetArgs{
			AssignIpv6AddressOnCreation: pulumi.Bool(false),
			CidrBlock:                   pulumi.String("172.16.160.0/19"),
			MapPublicIpOnLaunch:         pulumi.Bool(false),
			Tags: pulumi.StringMap{
				"Name":                            pulumi.String("pulumi-vpc-private-1"),
				"Owner":                           pulumi.String("pulumi"),
				"Project":                         pulumi.String("pulumi-k8s-aws-cluster"),
				"kubernetes.io/role/internal-elb": pulumi.String("1"),
				"type":                            pulumi.String("private"),
			},
			VpcId: pulumi.String("vpc-0ad77710973388316"),
		}, pulumi.Protect(true))
		if err != nil {
			return err
		}
		return nil
	})
}
using Pulumi;
using Aws = Pulumi.Aws;

class MyStack : Stack
{
    public MyStack()
    {
        var application_vpc = new Aws.Ec2.Vpc("application-vpc", new Aws.Ec2.VpcArgs
        {
            AssignGeneratedIpv6CidrBlock = false,
            CidrBlock = "172.16.0.0/16",
            EnableDnsSupport = true,
            InstanceTenancy = "default",
            Tags =
            {
                { "Name", "pulumi-vpc" },
                { "Owner", "pulumi" },
                { "Project", "pulumi-k8s-aws-cluster" },
            },
        }, new CustomResourceOptions
        {
            Protect = true,
        });
        var public_1 = new Aws.Ec2.Subnet("public-1", new Aws.Ec2.SubnetArgs
        {
            AssignIpv6AddressOnCreation = false,
            CidrBlock = "172.16.32.0/19",
            MapPublicIpOnLaunch = true,
            Tags =
            {
                { "Name", "pulumi-vpc-public-1" },
                { "Owner", "pulumi" },
                { "Project", "pulumi-k8s-aws-cluster" },
                { "kubernetes.io/role/elb", "1" },
                { "type", "public" },
            },
            VpcId = "vpc-0ad77710973388316",
        }, new CustomResourceOptions
        {
            Protect = true,
        });
        var private_1 = new Aws.Ec2.Subnet("private-1", new Aws.Ec2.SubnetArgs
        {
            AssignIpv6AddressOnCreation = false,
            CidrBlock = "172.16.160.0/19",
            MapPublicIpOnLaunch = false,
            Tags =
            {
                { "Name", "pulumi-vpc-private-1" },
                { "Owner", "pulumi" },
                { "Project", "pulumi-k8s-aws-cluster" },
                { "kubernetes.io/role/internal-elb", "1" },
                { "type", "private" },
            },
            VpcId = "vpc-0ad77710973388316",
        }, new CustomResourceOptions
        {
            Protect = true,
        });
    }

}

Check out the video clip below for a demo.

Documentation

Full CLI Documentation is available, showing all of the different import command flags. The flags include writing directly to a file and the ability to ensure a resource is not protected on import. Examples of importing resources can be found on their specifc resource documentation pages. Such an example for importing a VPC can be found in the VPC import documentation.
