Getting Started with Kubernetes: Stateful Applications

Posted on

This article is the fourth in a series using infrastructure as code to deploy applications with Kubernetes. This series walks you through:

In the previous post, we examined different methods for deploying applications. We worked through examples of a boilerplate deployment, to one using ComponentResources to automate deployment further, and deploying with Helm charts. In this installment, we’ll look at how to deploy stateful applications, such as databases, in Kubernetes. Unlike stateless applications, stateful apps require persistent storage, which presents scaling and availability challenges.

Stateful vs. Stateless

Stateless applications don’t require information from a previous transaction because they are single request and response. For example, the “Hello World” example that we deployed in an earlier article is a stateless application. The critical thing to remember is that in Kubernetes, any container with that application in any pod can respond to that request. Stateful applications can read or store information about previous transactions, and a transaction is executed within the context of a previous extraction. Email is an example of a stateful application; an email can be unread or read, or it can be grouped according to keywords or by content. In stateless applications, access to storage must be coordinated, either by sending all requests to the same Pod, or by synchronizing across multiple Pods.

Stateful sets

Stateful sets are the Kubernetes workload object for managing stateful applications. They are a specialized type of Deployments, where the Pods maintain a persistent identity during updates and rescheduling.

You would use a StatefulSet for:

  • stable and unique network identifiers
  • stable and persistent storage
  • applications that require ordered deployment and scaling
  • applications that require ordered and rolling updates

When a StatefulSet is created, each Pod is assigned a unique and persistent identifier. Pods are named numerically starting from 0, e.g., pod-0, pod-1, pod-n. StatefulSets use a Headless Service resource, which sets the clusterIP property to none. Pods in a StatefulSet will have an IP address mapped directly to them instead of a virtual IP address. This lets other Pods in the cluster directly communicate to an application, as in database connections.

StatefulSets can control the order of starting and stopping Pods. Some applications require a resource to be available before the Pod can be marked healthy. A Pod in a StatefulSet can be mounted to a dedicated persistent volume by declaring a PersistentVolumeClaim. If a Pod in a StatefulSet shuts down, the StatefulSet Controller will relaunch a replacement Pod with the same network identifier and reattach it to the persistent Volume.

StatefulSets have two update strategies. The OnDelete strategy does not automatically update the Pods, and they must be manually deleted for the controller to create new Pods. Rolling updates automatically deletes and creates a replacement for Pods in a StatefulSet. It creates replacement in the same order as they are deleted, which is from the highest to the smallest numbered Pod. A replacement Pod must be ‘Running and Ready’ before it replaces the preceding Pod.

Example

Let’s see how this works in practice with a MariaDB deployment in Kubernetes. The example begins with defining the cluster configuration and the MariaDB configuration using a ConfigMap. We’ll skip over this and go straight to the StatefulSet.

Headless Service

In the previous section, we described the Headless Service. The key parts are setting the ClusterIP to "None", which allocates an IP address and port so that applications can establish a database connection.

Deployment

Let’s look at the StatefulSet, step-by-step. The spec matches the StatefulSet to the Headless Service using a selector that matches the labels. We assign it a service name, specify a single replica, and a RollingUpdate update strategy. Note that this is the default update strategy, but it’s a good practice to declare it.

Pod scheduling

The next section declares variables for MariaDB, such as the serviceAccountName and the securityContext. However, of interest is the podAntiAffinity parameter, which ensures that the Pod will not be deployed on a Node with a Pod with the labels ‘mariadb’ and ‘example’. The weight is set for the preferred rule, where a node with a higher weight is preferred. We prevent another instance from being deployed on the same host by setting topologyKey: "kubernetes.io/hostname".

Putting it all together, we’ve told the Kubernetes Scheduler never to co-locate two Pods that have the app labels “mariadb” and “example” in the same domain (or Node) defined by setting topologyKey:”kubernetes.io/hostname”. These parameters control Pod scheduling to ensure that if a Pod is replaced, the new Pod is addressable by other resources in the application.

Configure the MariaDB container

The following section configures the MariaDB container. We’ll skip the part of the container configuration and look at healthchecks that impact the Pod’s scheduling. The livenessProbe is useful for detecting if a long-running application, such as a database, is broken and cannot recover except by a restart. In this example, we call the mysql init script as a status check. If the container fails the livenessProbe, the Kubernetes scheduler will kill the Pod and replace it. A readinessProbe is similar to a livenessProbe; if the probe fails, Kubernetes won’t send traffic to the Pod. Unlike a livenessProbe, the Pod remains running and is not terminated and replaced by the scheduler. Probe field or settings are described in the Kubernetes documentation.

We also configure two volumeMounts. The first volumeMount sets the MariaDB data path to the data Volume. The second volumeMount mounts the MariaDB configMap that was defined earlier.

Create a Volume for storage

The final section of code creates a Persistent Volume using a volumeClaimTemplate. This object requests a PVC (PersistentVolumeClaim) from the storage class dynamically. We set the accessModes to “ReadWriteOnce”, which means the volume can be mounted as read-write by a single node. Other accessModes are “ReadOnlyMany”, where the volume can be mounted read-only by many nodes, and “ReadWriteMany”, where the volume can be mounted as read-write by many nodes. We also set the size of the Volume to 8 gigabytes.

To summarize, we deployed MariaDB using a StatefulSet by creating a headlessService which assigns a persistent IP address to the Pod instead of using clusterIP and nodePorts to route traffic to the application. We then defined Node Affinity/AntiAffinity to set rules on which nodes are selected by the scheduler for creating Pods. Next, we configured the container and set livenessProbes and readinessProbes to tell the Scheduler if a Pod needs to be terminated and restarted or not to route traffic to the Pod until it is ready. We also configure volumeMounts and volumes to store configuration information and data for MariaDB.

Conclusion

Stateful applications present additional challenges when deployed in Kubernetes. Many applications require a stateful resource, such as a database or a component that maintains a login and session id. Stateful applications route traffic to a stable and persistent resource. Kubernetes accomplishes this with StatefulSets, which creates resources with a persistent id and unique address. We can configure scheduling and replacement of Pods, to allow resources to continue using a persistent id and address. We can also configure containers with health checks to signal if a Pod should be terminated or if it should continue to receive requests. We can also control which Node can access a PersistentVolume with a volumeClaimTemplate, and in our example, we limit access to only one Node. Make sure to try out the complete example on Github.

In the next series installment, we’ll examine Kubernetes networking. Until then, you can learn more about Kubernetes with these resources:
